Crystal structure of HCV NS5B polymerase with a novel pyridazinone inhibitor

Experimental Data Snapshot

  • Resolution: 2.10 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.218
  • R-Value Observed: 0.220

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.4 of the entry. See complete history


Pyrrolo[1,2-b]pyridazin-2-ones as potent inhibitors of HCV NS5B polymerase.

Ruebsam, F.Webber, S.E.Tran, M.T.Tran, C.V.Murphy, D.E.Zhao, J.Dragovich, P.S.Kim, S.H.Li, L.S.Zhou, Y.Han, Q.Kissinger, C.R.Showalter, R.E.Lardy, M.Shah, A.M.Tsan, M.Patel, R.Lebrun, L.A.Kamran, R.Sergeeva, M.V.Bartkowski, D.M.Nolan, T.G.Norris, D.A.Kirkovsky, L.

(2008) Bioorg Med Chem Lett 18: 3616-3621

  • DOI: https://doi.org/10.1016/j.bmcl.2008.04.066
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Pyrrolo[1,2-b]pyridazin-2-one analogs were discovered as a novel class of inhibitors of genotype 1 HCV NS5B polymerase. Structure-based design led to the discovery of compound 3 k, which displayed potent inhibitory activities in biochemical and replicon assays (IC(50) (1b)<10nM; EC(50) (1b)=12 nM) as well as good stability towards human liver microsomes (HLM t(1/2)>60 min).

  • Organizational Affiliation

    Anadys Pharmaceuticals, Inc., 3115 Merryfield Row, San Diego, CA 92121, USA. fruebsam@anadyspharma.com

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
RNA-directed RNA polymerase
A, B
578Hepatitis C virus (isolate BK)Mutation(s): 1
Find proteins for P26663 (Hepatitis C virus genotype 1b (isolate BK))
Explore P26663
Go to UniProtKB:  P26663
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP26663
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on 3MS

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
N-{3-[4-hydroxy-1-(3-methylbutyl)-2-oxo-1,2-dihydropyrrolo[1,2-b]pyridazin-3-yl]-1,1-dioxido-2H-1,2,4-benzothiadiazin-7 -yl}methanesulfonamide
C20 H23 N5 O6 S2
Binding Affinity Annotations
IDSourceBinding Affinity
3MS BindingDB:  3CO9 IC50: 10 (nM) from 1 assay(s)
EC50: 8.5 (nM) from 1 assay(s)
PDBBind:  3CO9 IC50: 10 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Resolution: 2.10 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.218
  • R-Value Observed: 0.220
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.701α = 90
b = 106.423β = 90
c = 126.431γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-02-10
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2021-10-20
    Changes: Database references, Derived calculations, Structure summary
  • Version 1.3: 2024-02-21
    Changes: Data collection
  • Version 1.4: 2024-04-03
    Changes: Refinement description
