3CDL | pdb_00003cdl

Crystal structure of a TetR family transcriptional regulator from Pseudomonas syringae pv. tomato str. DC3000

PDB DOI: https://doi.org/10.2210/pdb3CDL/pdb

Classification: TRANSCRIPTION REGULATOR
Organism(s): Pseudomonas syringae pv. tomato str. DC3000
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2008-02-27 Released: 2008-03-18
Deposition Author(s): Tan, K., Bigelow, L., Gu, M., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.36 Å
R-Value Free:
0.275 (Depositor), 0.282 (DCC)
R-Value Work:
0.207 (Depositor)
R-Value Observed:
0.210 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3CDL

This is version 1.2 of the entry. See complete history.

Literature

The crystal structure of a TetR family transcriptional regulator from Pseudomonas syringae pv. tomato str. DC3000.

Tan, K., Bigelow, L., Gu, M., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 46.87 kDa
Atom Count: 3,068
Modeled Residue Count: 375
Deposited Residue Count: 406
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transcriptional regulator AefR	A, B	203	Pseudomonas syringae pv. tomato str. DC3000	Mutation(s): 0 Gene Names: aefR, PSPTO3549
UniProt
Find proteins for Q87Z81 (Pseudomonas syringae pv. tomato (strain ATCC BAA-871 / DC3000)) Explore Q87Z81 Go to UniProtKB: Q87Z81
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q87Z81
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.36 Å
R-Value Free: 0.275 (Depositor), 0.282 (DCC)
R-Value Work: 0.207 (Depositor)
R-Value Observed: 0.210 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 132.305	α = 90
b = 53.409	β = 113.25
c = 55.829	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
SHELXD	phasing
MLPHARE	phasing
DM	phasing
RESOLVE	phasing
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2008-03-18

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2008-03-18
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.2: 2024-11-13
Changes: Data collection, Database references, Derived calculations, Structure summary
