3BNI | pdb_00003bni

Crystal structure of TetR-family transcriptional regulator from Streptomyces coelicolor

PDB DOI: https://doi.org/10.2210/pdb3BNI/pdb

Classification: TRANSCRIPTION REGULATOR
Organism(s): Streptomyces coelicolor A3(2)
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2007-12-14 Released: 2007-12-25
Deposition Author(s): Osipiuk, J., Xu, X., Gu, J., Savchenko, A., Edwards, A.M., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.249 (Depositor), 0.249 (DCC)
R-Value Work:
0.197 (Depositor), 0.195 (DCC)
R-Value Observed:
0.200 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3BNI

This is version 1.3 of the entry. See complete history.

Literature

X-ray crystal structure of TetR-family transcriptional regulator from Streptomyces coelicolor.

Osipiuk, J., Xu, X., Gu, J., Savchenko, A., Edwards, A.M., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 51.94 kDa
Atom Count: 2,832
Modeled Residue Count: 345
Deposited Residue Count: 458
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative TetR-family transcriptional regulator	A, B	229	Streptomyces coelicolor A3(2)	Mutation(s): 0 Gene Names: SCO1712, SCI11.01c, SCI30A.33c
UniProt
Find proteins for Q8CK21 (Streptomyces coelicolor (strain ATCC BAA-471 / A3(2) / M145)) Explore Q8CK21 Go to UniProtKB: Q8CK21
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8CK21
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PG4 Query on PG4 Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	TETRAETHYLENE GLYCOL C₈ H₁₈ O₅ UWHCKJMYHZGTIT-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.249 (Depositor), 0.249 (DCC)
R-Value Work: 0.197 (Depositor), 0.195 (DCC)
R-Value Observed: 0.200 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.091	α = 90
b = 66.354	β = 90
c = 125.083	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
HKL-2000	data reduction
SHELXD	phasing
MLPHARE	phasing
DM	phasing
SOLVE	phasing
RESOLVE	phasing
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-12-25

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2007-12-25
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2017-10-25
Changes: Refinement description
Version 1.3: 2024-02-21
Changes: Data collection, Database references, Derived calculations
