3BHG | pdb_00003bhg

Crystal structure of adenylosuccinate lyase from Legionella pneumophila

• PDB DOI: https://doi.org/10.2210/pdb3BHG/pdb

• Classification: LYASE
• Organism(s): Legionella pneumophila subsp. pneumophila str. Philadelphia 1
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2007-11-28 Released: 2007-12-04
• Deposition Author(s): Chang, C., Li, H., Freeman, L., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:
  0.195 (Depositor), 0.194 (DCC)
• R-Value Work:
  0.166 (Depositor), 0.165 (DCC)
• R-Value Observed:
  0.168 (Depositor)

Literature

Crystal structure of adenylosuccinate lyase from Legionella pneumophila.

Chang, C., Li, H., Freeman, L., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 52.58 kDa
• Atom Count: 3,819
• Modeled Residue Count: 448
• Deposited Residue Count: 459
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Adenylosuccinate lyase	A	459	Legionella pneumophila subsp. pneumophila str. Philadelphia 1	Mutation(s): 0  Gene Names: lpg0801 EC: 4.3.2.2
UniProt
Find proteins for Q5ZXD1 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)) Explore Q5ZXD1  Go to UniProtKB:  Q5ZXD1

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	B [auth A], C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
GOL	D [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:  0.195 (Depositor), 0.194 (DCC)
• R-Value Work:  0.166 (Depositor), 0.165 (DCC)
• R-Value Observed: 0.168 (Depositor)

Space Group: I 4₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 109.216	α = 90
b = 109.216	β = 90
c = 157.099	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-2000	data reduction
HKL-3000	data scaling
HKL-3000	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-12-04
Deposition Author(s): Chang, C., Li, H., Freeman, L., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2007-12-04
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2024-10-30
  Changes: Data collection, Database references, Derived calculations, Structure summary
