3AKT

Crystal structure of xylanase from Trichoderma longibrachiatum

• PDB DOI: https://doi.org/10.2210/pdb3AKT/pdb

• Classification: HYDROLASE
• Organism(s): Trichoderma longibrachiatum
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2010-07-15 Released: 2011-06-01
• Deposition Author(s): Sugahara, M., Kunishima, N.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.00 Å
• R-Value Free: 0.186
• R-Value Work: 0.182
• R-Value Observed: 0.182

Literature

Packing Space Expansion of Protein Crystallization Screening with Synthetic Zeolite as a Heteroepitaxic Nucleant

Sugahara, M., Kageyama-Morikawa, Y., Kunishima, N.

(2011) Cryst Growth Des 11: 110-120

• DOI: https://doi.org/10.1021/cg100987g

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 41.95 kDa
• Atom Count: 3,436
• Modelled Residue Count: 380
• Deposited Residue Count: 380
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
xylanase	A, B	190	Trichoderma longibrachiatum	Mutation(s): 0  EC: 3.2.1.8
UniProt
Find proteins for F8W669 (Trichoderma longibrachiatum) Explore F8W669  Go to UniProtKB:  F8W669

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	C [auth A], D [auth A], E [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
PCA	A, B	L-PEPTIDE LINKING	C5 H7 N O3		GLN

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.00 Å
• R-Value Free: 0.186
• R-Value Work: 0.182
• R-Value Observed: 0.182
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.765	α = 90
b = 38.841	β = 94.78
c = 81.337	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
MOLREP	phasing
CNS	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-06-01
Deposition Author(s): Sugahara, M., Kunishima, N.

Revision History

• Version 1.0: 2011-06-01
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 2.0: 2019-12-25
  Changes: Derived calculations, Polymer sequence
• Version 2.1: 2023-11-01
  Changes: Data collection, Database references, Derived calculations, Refinement description
