3AK4 | pdb_00003ak4

Crystal structure of NADH-dependent quinuclidinone reductase from agrobacterium tumefaciens

• PDB DOI: https://doi.org/10.2210/pdb3AK4/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Agrobacterium tumefaciens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2010-07-07 Released: 2011-07-13
• Deposition Author(s): Miyakawa, T., Kataoka, M., Takeshita, D., Nomoto, F., Nagata, K., Shimizu, S., Tanokura, M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.191 (Depositor), 0.160 (DCC)
• R-Value Work:
  0.149 (Depositor), 0.150 (DCC)
• R-Value Observed:
  0.151 (Depositor)

Starting Model: experimental

Literature

Crystal structure of NADH-dependent quinuclidinone reductase from Agrobacterium tumefaciens

Miyakawa, T., Kataoka, M., Takeshita, D., Nomoto, F., Nagata, K., Shimizu, S., Tanokura, M.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 113.01 kDa
• Atom Count: 8,592
• Modeled Residue Count: 1,032
• Deposited Residue Count: 1,052
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-dependent quinuclidinone reductase	A, B, C, D	263	Agrobacterium tumefaciens	Mutation(s): 0
UniProt
Find proteins for G1K3P5 (Agrobacterium tumefaciens) Explore G1K3P5  Go to UniProtKB:  G1K3P5

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAD	E [auth A], F [auth B], G [auth C], H [auth D]	NICOTINAMIDE-ADENINE-DINUCLEOTIDE C21 H27 N7 O14 P2 BAWFJGJZGIEFAR-NNYOXOHSSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.191 (Depositor), 0.160 (DCC)
• R-Value Work:  0.149 (Depositor), 0.150 (DCC)
• R-Value Observed: 0.151 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.55	α = 90
b = 127.3	β = 110.4
c = 62.48	γ = 90

Software Package:

Software Name	Purpose
CrystalClear	data collection
MOLREP	phasing
REFMAC	refinement
XDS	data reduction
XSCALE	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-07-13
Deposition Author(s): Miyakawa, T., Kataoka, M., Takeshita, D., Nomoto, F., Nagata, K., Shimizu, S., Tanokura, M.

Revision History

• Version 1.0: 2011-07-13
  Type: Initial release

• Version 1.1: 2023-11-01
  Changes: Data collection, Database references, Derived calculations, Refinement description
