3AH3

Crystal structure of LR5-1, 3-isopropylmalate dehydrogenase created by directed evolution


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.4 Å
  • R-Value Free: 0.267
  • R-Value Work: 0.216

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Enhancement of the latent 3-isopropylmalate dehydrogenase activity of promiscuous homoisocitrate dehydrogenase by directed evolution

Suzuki, Y.Asada, K.Miyazaki, J.Tomita, T.Kuzuyama, T.Nishiyama, M.

(2010) Biochem.J. 431: 401-410

  • DOI: 10.1042/BJ20101246

  • PubMed Abstract:
  • HICDH (homoisocitrate dehydrogenase), which is involved in lysine biosynthesis through α-aminoadipate, is a paralogue of IPMDH [3-IPM (3-isopropylmalate) dehydrogenase], which is involved in leucine biosynthesis. TtHICDH (Thermus thermophilus HICDH) ...

    HICDH (homoisocitrate dehydrogenase), which is involved in lysine biosynthesis through α-aminoadipate, is a paralogue of IPMDH [3-IPM (3-isopropylmalate) dehydrogenase], which is involved in leucine biosynthesis. TtHICDH (Thermus thermophilus HICDH) can recognize isocitrate, as well as homoisocitrate, as the substrate, and also shows IPMDH activity, although at a considerably decreased rate. In the present study, the promiscuous TtHICDH was evolved into an enzyme showing distinct IPMDH activity by directed evolution using a DNA-shuffling technique. Through five repeats of DNA shuffling/screening, variants that allowed Escherichia coli C600 (leuB⁻) to grow on a minimal medium in 2 days were obtained. One of the variants LR5-1, with eight amino acid replacements, was found to possess a 65-fold increased k(cat)/K(m) value for 3-IPM, compared with TtHICDH. Introduction of a single back-replacement H15Y change caused a further increase in the k(cat)/K(m) value and a partial recovery of the decreased thermotolerance of LR5-1. Site-directed mutagenesis revealed that most of the amino acid replacements found in LR5-1 effectively increased IPMDH activity; replacements around the substrate-binding site contributed to the improved recognition for 3-IPM, and other replacements at sites away from the substrate-binding site enhanced the turnover number for the IPMDH reaction. The crystal structure of LR5-1 was determined at 2.4 Å resolution and revealed that helix α4 was displaced in a manner suitable for recognition of the hydrophobic γ-moiety of 3-IPM. On the basis of the crystal structure, possible reasons for enhancement of the turnover number are discussed.


    Organizational Affiliation

    Biotechnology Research Center, University of Tokyo, Bunkyo-ku, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Homoisocitrate dehydrogenase
A, B, C, D
334Thermus thermophilus (strain HB27 / ATCC BAA-163 / DSM 7039)Mutation(s): 0
Gene Names: hicd (hdh, hicdh)
EC: 1.1.1.87
Find proteins for Q72IW9 (Thermus thermophilus (strain HB27 / ATCC BAA-163 / DSM 7039))
Go to UniProtKB:  Q72IW9
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B, C, D
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
EDO
Query on EDO

Download SDF File
Download CCD File
A, B, C, D
1,2-ETHANEDIOL
ETHYLENE GLYCOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.4 Å
  • R-Value Free: 0.267
  • R-Value Work: 0.216
  • Space Group: P 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 83.335α = 90.00
b = 61.737β = 98.28
c = 170.054γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data scaling
PHASERphasing
REFMACrefinement
HKL-2000data collection
HKL-2000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2011-02-02
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
