2ZY3 | pdb_00002zy3

dodecameric L-aspartate beta-decarboxylase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:
    0.234 (Depositor), 0.234 (DCC)
  • R-Value Work:
    0.175 (Depositor), 0.175 (DCC)
  • R-Value Observed:
    0.178 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2ZY3

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Structure, Assembly, and Mechanism of a PLP-Dependent Dodecameric l-Aspartate beta-Decarboxylase

Chen, H.-J.Ko, T.-P.Lee, C.-Y.Wang, N.-C.Wang, A.H.-J.

(2009) Structure 17: 517-529

  • DOI: https://doi.org/10.1016/j.str.2009.02.013
  • Primary Citation Related Structures:
    2ZY2, 2ZY3, 2ZY4, 2ZY5

  • PubMed Abstract:

    The type-I PLP enzyme l-aspartate beta-decarboxylase converts aspartate to alanine and CO(2). Similar to the homodimeric aminotransferases, its protein subunit comprises a large and a small domain, of 410 and 120 residues, respectively. The crystal structure reveals a dodecamer made of six identical dimers arranged in a truncated tetrahedron whose assembly involves tetramer and hexamer as intermediates. The additional helical motifs I and II participate in the oligomer formation. Triple mutations of S67R/Y68R/M69R or S67E/Y68E/M69E in motif I produced an inactive dimer. The PLP is bound covalently to Lys315 in the active site, while its phosphate group interacts with a neighboring Tyr134. Removal of the bulky side chain of Arg37, which overhangs the PLP group, improved the substrate affinity. Mutations in flexible regions produced the more active K17A and the completely inactive R487A. The structure also suggests that substrate binding triggers conformational changes essential for catalyzing the reaction.


  • Organizational Affiliation
    • Institute of Biological Chemistry, Academia Sinica, Taipei 11529, Taiwan.

Macromolecule Content

  • Total Structure Weight: 368.52 kDa
  • Atom Count: 26,599
  • Modeled Residue Count: 3,090
  • Deposited Residue Count: 3,276
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
L-aspartate beta-decarboxylase
A, B, C, D, E
A, B, C, D, E, F
546Alcaligenes faecalis subsp. faecalisMutation(s): 0
Gene Names: asdA-AF
EC: 4.1.1.12 (PDB Primary Data), 2.6.1.1 (UniProt)
UniProt
Find proteins for Q93QX0 (Comamonas testosteroni)
Explore Q93QX0
Go to UniProtKB:  Q93QX0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ93QX0
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:  0.234 (Depositor), 0.234 (DCC)
  • R-Value Work:  0.175 (Depositor), 0.175 (DCC)
  • R-Value Observed: 0.178 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 149.734α = 90
b = 216.141β = 90
c = 208.726γ = 90
Software Package:
Software NamePurpose
Blu-Icedata collection
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling
CNSphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-01-27
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.2: 2017-10-11
    Changes: Refinement description
  • Version 1.3: 2023-11-01
    Changes: Data collection, Database references, Derived calculations, Refinement description
