High resolution structure of Colicin M

Experimental Data Snapshot

  • Resolution: 1.67 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.157
  • R-Value Observed: 0.160

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Activation of Colicin M by the Fkpa Prolyl Cis- Trans Isomerase/Chaperone.

Helbig, S.Patzer, S.I.Schiene-Fischer, C.Zeth, K.Braun, V.

(2011) J Biol Chem 286: 6280

  • DOI: https://doi.org/10.1074/jbc.M110.165274
  • Primary Citation of Related Structures:
    2XMX, 2XTQ, 2XTR

  • PubMed Abstract:

    Colicin M (Cma) is specifically imported into the periplasm of Escherichia coli and kills the cells. Killing depends on the periplasmic peptidyl prolyl cis-trans isomerase/chaperone FkpA. To identify the Cma prolyl bonds targeted by FkpA, we replaced the 15 proline residues individually with alanine. Seven mutant proteins were fully active; Cma(P129A), Cma(P176A), and Cma(P260A) displayed 1%, and Cma(P107A) displayed 10% of the wild-type activity. Cma(P107A), Cma(P129A), and Cma(P260A), but not Cma(P176A), killed cells after entering the periplasm via osmotic shock, indicating that the former mutants were translocation-deficient; Cma(P129A) did not bind to the FhuA outer membrane receptor. The crystal structures of Cma and Cma(P176A) were identical, excluding inactivation of the activity domain located far from Pro-176. In a new peptidyl prolyl cis-trans isomerase assay, FkpA isomerized the Cma prolyl bond in peptide Phe-Pro-176 at a high rate, but Lys-Pro-107 and Leu-Pro-260 isomerized at only <10% of that rate. The four mutant proteins secreted into the periplasm via a fused signal sequence were toxic but much less than wild-type Cma. Wild-type and mutant Cma proteins secreted or translocated across the outer membrane by energy-coupled import or unspecific osmotic shock were only active in the presence of FkpA. We propose that Cma unfolds during transfer across the outer or cytoplasmic membrane and refolds to the active form in the periplasm assisted by FkpA. Weak refolding of Cma(P176A) would explain its low activity in all assays. Of the four proline residues identified as being important for Cma activity, Phe-Pro-176 is most likely targeted by FkpA.

  • Organizational Affiliation

    Max Planck Institute for Developmental Biology, Spemannstrasse 35, 72076 Tübingen, Germany.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B
271Escherichia coli K-12Mutation(s): 0
Find proteins for P05820 (Escherichia coli)
Explore P05820
Go to UniProtKB:  P05820
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP05820
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.67 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.157
  • R-Value Observed: 0.160
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 52.757α = 90
b = 115.007β = 90
c = 227.714γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-12-29
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-12-20
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
