Structure of Bug27 from Bordetella pertussis

Experimental Data Snapshot

  • Resolution: 1.92 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.191
  • R-Value Observed: 0.194

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


Structure-based mechanism of ligand binding for periplasmic solute-binding protein of the Bug family.

Herrou, J.Bompard, C.Antoine, R.Leroy, A.Rucktooa, P.Hot, D.Huvent, I.Locht, C.Villeret, V.Jacob-Dubuisson, F.

(2007) J Mol Biol 373: 954-964

  • DOI: https://doi.org/10.1016/j.jmb.2007.08.006
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Bug proteins form a large family of periplasmic solute-binding proteins well represented in beta-proteobacteria. They adopt a characteristic Venus flytrap fold with two globular domains bisected by a ligand-binding cleft. The structures of two liganded Bug proteins have revealed that the family is specific for carboxylated solutes, with a characteristic mode of binding involving two highly conserved beta strand-beta turn-alpha helix motifs originating from each domain. These two motifs form hydrogen bonds with a carboxylate group of the ligand, both directly and via conserved water molecules, and have thus been termed the carboxylate pincers. In both crystallized Bug proteins, the ligands were found enclosed between the two domains and inaccessible to solvent, suggesting an inter-domain hinge-bending motion upon ligand binding. We report here the first structures of an open, unliganded Bug protein and of the same protein with a citrate ion bound in the open cavity. One of the ligand carboxylate groups is bound to one half of the carboxylate pincers by the beta strand-beta turn-alpha helix motif from domain 1, and the citrate ion forms several additional interactions with domain 1. The ligand is accessible to solvent and has very few contacts with domain 2. In this open, liganded structure, the second part of the carboxylate pincers originating from domain 2 is not stabilized by ligand binding, and a loop replaces the beta turn. In the unliganded structure, both motifs of the carboxylate pincers are highly mobile, and neither of the two beta turns is formed. Thus, ligand recognition is performed by domain 1, with the carboxylate group serving as an initial anchoring point. Stabilization of the closed conformation requires proper interactions to be established with domain 2, and thus domain 2 discriminates between productively and non-productively bound ligands.

  • Organizational Affiliation

    INSERM U629, 1 Rue du Pr Calmette, 59019 Lille cedex, France.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
protein Bug27
A, B, C
301Bordetella pertussisMutation(s): 0
Gene Names: 2667749
Find proteins for Q7W019 (Bordetella pertussis (strain Tohama I / ATCC BAA-589 / NCTC 13251))
Explore Q7W019
Go to UniProtKB:  Q7W019
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7W019
Sequence Annotations
  • Reference Sequence
Small Molecules
Binding Affinity Annotations
IDSourceBinding Affinity
CIT PDBBind:  2QPQ Kd: 430 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Resolution: 1.92 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.191
  • R-Value Observed: 0.194
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 72.39α = 90
b = 82.31β = 95.35
c = 87.47γ = 90
Software Package:
Software NamePurpose
MAR345dtbdata collection
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-08-21
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
