2NZW

Crystal Structure of alpha1,3-Fucosyltransferase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.9 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.191

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Structure and mechanism of Helicobacter pylori fucosyltransferase. A basis for lipopolysaccharide variation and inhibitor design.

Sun, H.Y.Lin, S.W.Ko, T.P.Pan, J.F.Liu, C.L.Lin, C.N.Wang, A.H.Lin, C.H.

(2007) J. Biol. Chem. 282: 9973-9982

  • DOI: 10.1074/jbc.M610285200
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Helicobacter pylori alpha1,3-fucosyltransferase (FucT) is involved in catalysis to produce the Lewis x trisaccharide, the major component of the bacteria's lipopolysaccharides, which has been suggested to mimic the surface sugars in gastric epitheliu ...

    Helicobacter pylori alpha1,3-fucosyltransferase (FucT) is involved in catalysis to produce the Lewis x trisaccharide, the major component of the bacteria's lipopolysaccharides, which has been suggested to mimic the surface sugars in gastric epithelium to escape host immune surveillance. We report here three x-ray crystal structures of FucT, including the FucT.GDP-fucose and FucT.GDP complexes. The protein structure is typical of the glycosyltransferase-B family despite little sequence homology. We identified a number of catalytically important residues, including Glu-95, which serves as the general base, and Glu-249, which stabilizes the developing oxonium ion during catalysis. The residues Arg-195, Tyr-246, Glu-249, and Lys-250 serve to interact with the donor substrate, GDP-fucose. Variations in the protein and ligand conformations, as well as a possible FucT dimer, were also observed. We propose a catalytic mechanism and a model of polysaccharide binding not only to explain the observed variations in H. pylori lipopolysaccharides, but also to facilitate the development of potent inhibitors.


    Organizational Affiliation

    Institute of Biochemical Sciences, National Taiwan University, Taipei 10642, Taiwan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Alpha1,3-fucosyltransferase
A, B, C
371Helicobacter pyloriMutation(s): 0
Gene Names: fucT
EC: 2.4.1.152
Find proteins for O30511 (Helicobacter pylori)
Go to UniProtKB:  O30511
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
B, C
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.9 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.191
  • Space Group: P 21 21 2
Unit Cell:
Length (Å)Angle (°)
a = 104.545α = 90.00
b = 136.196β = 90.00
c = 96.829γ = 90.00
Software Package:
Software NamePurpose
SOLVEphasing
HKL-2000data scaling
HKL-2000data reduction
HKL-2000data collection
CNSrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

  • Deposited Date: 2006-11-27
  • Released Date: 2007-01-23
  • Deposition Author(s): Sun, H.Y., Ko, T.P.

Revision History

  • Version 1.0: 2007-01-23
    Type: Initial release
  • Version 1.1: 2008-05-01
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2017-07-05
    Type: Database references
