Structure of the DAP12 transmembrane homodimer

Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 75
  • Conformers Submitted: 15
  • Selection Criteria: structures with the lowest energy

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


The structural basis for intramembrane assembly of an activating immunoreceptor complex.

Call, M.E.Wucherpfennig, K.W.Chou, J.J.

(2010) Nat Immunol 11: 1023-1029

  • DOI: https://doi.org/10.1038/ni.1943
  • Primary Citation of Related Structures:
    2L34, 2L35

  • PubMed Abstract:

    Many receptors that activate cells of the immune system are multisubunit membrane protein complexes in which ligand recognition and signaling functions are contributed by separate protein modules. Receptors and signaling subunits assemble through contacts among basic and acidic residues in their transmembrane domains to form the functional complexes. Here we report the nuclear magnetic resonance (NMR) structure of the membrane-embedded, heterotrimeric assembly formed by association of the DAP12 signaling module with the natural killer (NK) cell-activating receptor NKG2C. The main intramembrane contact site is formed by a complex electrostatic network involving five hydrophilic transmembrane residues. Functional mutagenesis demonstrated that similar polar intramembrane motifs are also important for assembly of the NK cell-activating NKG2D-DAP10 complex and the T cell antigen receptor (TCR)-invariant signaling protein CD3 complex. This structural motif therefore lies at the core of the molecular organization of many activating immunoreceptors.

  • Organizational Affiliation

    Department of Biological Chemistry and Molecular Pharmacology, Harvard Medical School, Boston, Massachusetts, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
TYRO protein tyrosine kinase-binding protein
A, B
33Homo sapiensMutation(s): 0
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for O43914 (Homo sapiens)
Explore O43914
Go to UniProtKB:  O43914
GTEx:  ENSG00000011600
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO43914
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 75
  • Conformers Submitted: 15
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-11-03
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
