Crystal structure of IS200 transposase

Experimental Data Snapshot

  • Resolution: 1.70 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.213
  • R-Value Observed: 0.213

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Crystal Structure of a Metal Ion-bound IS200 Transposase

Lee, H.H.Yoon, J.Y.Kim, H.S.Kang, J.Y.Kim, K.H.Kim, D.J.Ha, J.Y.Mikami, B.Yoon, H.J.Suh, S.W.

(2006) J Biol Chem 281: 4261-4266

  • DOI: https://doi.org/10.1074/jbc.M511567200
  • Primary Citation of Related Structures:
    2F4F, 2F5G

  • PubMed Abstract:

    IS200 transposases, present in many bacteria and Archaea, appear to be distinct from other groups of transposases. To provide a structural basis for understanding the action of IS200 transposases, we have determined the crystal structure of the SSO1474 protein from Sulfolobus solfataricus, a member of the IS200 family, in both Mn(2+)-bound and Mn(2+)-free forms. Its monomer fold is distinct from other classes of structurally characterized transposases. Two monomers form a tight dimer by exchanging the C-terminal alpha-helix and by merging the two central beta-sheets into a large beta-sheet. Glu(55), His(62), and four water molecules provide the direct coordination sphere of the catalytically essential metal ion in the Mn(2+)-bound structure. His(16), Asp(59), and His(60) also play important roles in maintaining the metal binding site. The catalytic site is formed at the interface between monomers. The candidate nucleophile in the transposition mechanism, strictly conserved Tyr(121) coming from the other monomer, is turned away from the active site, suggesting that a conformational change is likely to occur during the catalytic cycle.

  • Organizational Affiliation

    Department of Chemistry, College of Natural Sciences, Seoul National University, Korea.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Transposase, putative
A, B
133Saccharolobus solfataricusMutation(s): 0
Find proteins for Q97Y68 (Saccharolobus solfataricus (strain ATCC 35092 / DSM 1617 / JCM 11322 / P2))
Explore Q97Y68
Go to UniProtKB:  Q97Y68
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ97Y68
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.70 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.213
  • R-Value Observed: 0.213
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.543α = 90
b = 68.149β = 129.24
c = 65.49γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-12-13
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-03-13
    Changes: Data collection, Database references
