2ZZL

Structure of bacteriorhodopsin's M intermediate at pH 7


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.03 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.207

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Crystal Structures of Different Substates of Bacteriorhodopsin's M Intermediate at Various pH Levels.

Yamamoto, M.Hayakawa, N.Murakami, M.Kouyama, T.

(2009) J.Mol.Biol. --: --

  • DOI: 10.1016/j.jmb.2009.08.047

  • PubMed Abstract:
  • The hexagonal P622 crystal of bacteriorhodopsin, which is made up of stacked membranes, is stable provided that the precipitant concentration in the soaking solution is higher than a critical value (i.e., 1.5 M ammonium sulfate). Diffraction data sho ...

    The hexagonal P622 crystal of bacteriorhodopsin, which is made up of stacked membranes, is stable provided that the precipitant concentration in the soaking solution is higher than a critical value (i.e., 1.5 M ammonium sulfate). Diffraction data showed that the crystal lattice shrank linearly with increasing precipitant concentration, due primarily to narrowing of intermembrane spaces. Although the crystal shrinkage did not affect the rate of formation of the photoreaction M intermediate, its lifetime increased exponentially with the precipitant concentration. It was suggested that the energetic barrier of the M-to-N transition becomes higher when the motional freedom of the EF loop is reduced by crystal lattice force. As a result of this property, the M state accumulated predominantly when the crystal that was soaked at a high precipitant concentration was illuminated at room temperature. Structural data obtained at various pH levels showed that the overall structure of M is not strongly dependent on pH, except that Glu194 and Glu204 in the proton release complex are more separated at pH 7 than at pH 4.4. This result suggests that light-induced disruption of the paired structure of Glu194 and Glu204 is incomplete when external pH is lower than the pK(a) value of the proton release group in the M state.


    Organizational Affiliation

    Department of Physics, Graduate School of Science, Nagoya University, Nagoya, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Bacteriorhodopsin
A
262Halobacterium salinarum (strain ATCC 700922 / JCM 11081 / NRC-1)Gene Names: bop
Find proteins for P02945 (Halobacterium salinarum (strain ATCC 700922 / JCM 11081 / NRC-1))
Go to UniProtKB:  P02945
Small Molecules
Ligands 8 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SGA
Query on SGA

Download SDF File
Download CCD File
A
O3-SULFONYLGALACTOSE
C6 H12 O9 S
HHRMGTRTCHNCRO-FDROIEKHSA-N
 Ligand Interaction
MAN
Query on MAN

Download SDF File
Download CCD File
A
ALPHA-D-MANNOSE
C6 H12 O6
WQZGKKKJIJFFOK-PQMKYFCFSA-N
 Ligand Interaction
L1P
Query on L1P

Download SDF File
Download CCD File
A
3-PHOSPHORYL-[1,2-DI-PHYTANYL]GLYCEROL
1,2-DI-1-(3,7,11,15-TETRAMETHYL-HEXADECANE)-SN-GLYCERO-3-PHOSPHATE
C43 H89 O6 P
UKQGAMWGTOTQPC-ALOLAALWSA-N
 Ligand Interaction
RET
Query on RET

Download SDF File
Download CCD File
A
RETINAL
C20 H28 O
NCYCYZXNIZJOKI-OVSJKPMPSA-N
 Ligand Interaction
SOG
Query on SOG

Download SDF File
Download CCD File
A
2-HYDROXYMETHYL-6-OCTYLSULFANYL-TETRAHYDRO-PYRAN-3,4,5-TRIOL
1-S-OCTYL-BETA-D-THIOGLUCOSIDE
C14 H28 O5 S
CGVLVOOFCGWBCS-RGDJUOJXSA-N
 Ligand Interaction
GLC
Query on GLC

Download SDF File
Download CCD File
A
ALPHA-D-GLUCOSE
C6 H12 O6
WQZGKKKJIJFFOK-DVKNGEFBSA-N
 Ligand Interaction
L2P
Query on L2P

Download SDF File
Download CCD File
A
2,3-DI-PHYTANYL-GLYCEROL
1,2-DI-1-(3,7,11,15-TETRAMETHYL-HEXADECANE)-SN-GLYCEROL
C43 H88 O3
ISDBCJSGCHUHFI-UMZPFTBHSA-N
 Ligand Interaction
L3P
Query on L3P

Download SDF File
Download CCD File
A
2,3-DI-O-PHYTANLY-3-SN-GLYCERO-1-PHOSPHORYL-3'-SN-GLYCEROL-1'-PHOSPHATE
C46 H94 O11 P2
TZXJQSKPTCRGCA-VZSPAKCESA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.03 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.207
  • Space Group: P 6 2 2
Unit Cell:
Length (Å)Angle (°)
a = 102.210α = 90.00
b = 102.210β = 90.00
c = 112.480γ = 120.00
Software Package:
Software NamePurpose
SCALAdata scaling
CNSrefinement
MOSFLMdata reduction
CNSphasing
MAR345dtbdata collection

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2009-10-06
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
