2YXH | pdb_00002yxh

Crystal structure of mazG-related protein from Thermotoga maritima

• PDB DOI: https://doi.org/10.2210/pdb2YXH/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Thermotoga maritima MSB8
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2007-04-26 Released: 2007-10-30
• Deposition Author(s): Padmanabhan, B., Bessho, Y., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.263 (Depositor)
• R-Value Work:
  0.212 (Depositor)
• R-Value Observed:
  0.215 (Depositor)

Literature

Crystal structure of mazG-related protein from Thermotoga maritima

Padmanabhan, B., Bessho, Y., Yokoyama, S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA,PQS (software)

Macromolecule Content

• Total Structure Weight: 27.51 kDa
• Atom Count: 2,142
• Modeled Residue Count: 228
• Deposited Residue Count: 232
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MazG-related protein	A, B	116	Thermotoga maritima MSB8	Mutation(s): 1
UniProt
Find proteins for Q9WYJ5 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9WYJ5  Go to UniProtKB:  Q9WYJ5

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MG	C [auth A], D [auth A], E [auth B], F [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.263 (Depositor)
• R-Value Work:  0.212 (Depositor)
• R-Value Observed: 0.215 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.829	α = 90
b = 56.788	β = 90
c = 61.615	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
ADSC	data collection
HKL-2000	data reduction
SCALEPACK	data scaling
SOLVE	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-10-30
Deposition Author(s): Padmanabhan, B., Bessho, Y., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History

• Version 1.0: 2007-10-30
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Derived calculations, Source and taxonomy, Version format compliance
• Version 1.2: 2021-11-10
  Changes: Database references, Derived calculations
• Version 1.3: 2024-05-29
  Changes: Data collection
• Version 1.4: 2024-10-30
  Changes: Structure summary
