2YXD | pdb_00002yxd

Crystal Structure of Cobalamin biosynthesis precorrin 8W decarboxylase (cbiT)

• PDB DOI: https://doi.org/10.2210/pdb2YXD/pdb

• Classification: TRANSFERASE
• Organism(s): Methanocaldococcus jannaschii DSM 2661
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2007-04-26 Released: 2007-10-30
• Deposition Author(s): Padmanabhan, B., Bessho, Y., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.273 (Depositor)
• R-Value Work:
  0.198 (Depositor)
• R-Value Observed:
  0.202 (Depositor)

Literature

Crystal Structure of Cobalamin biosynthesis precorrin 8W decarboxylase (cbiT)

Padmanabhan, B., Bessho, Y., Yokoyama, S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PQS (software)

Biological Assembly 2

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 41.83 kDa
• Atom Count: 2,893
• Modeled Residue Count: 360
• Deposited Residue Count: 366
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable cobalt-precorrin-6Y C(15)-methyltransferase [decarboxylating]	A, B	183	Methanocaldococcus jannaschii DSM 2661	Mutation(s): 0  Gene Names: cbiT EC: 2.1.1 (PDB Primary Data), 2.1.1.196 (UniProt)
UniProt
Find proteins for Q57836 (Methanocaldococcus jannaschii (strain ATCC 43067 / DSM 2661 / JAL-1 / JCM 10045 / NBRC 100440)) Explore Q57836  Go to UniProtKB:  Q57836

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MES	E [auth B]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C6 H13 N O4 S SXGZJKUKBWWHRA-UHFFFAOYSA-N
SO4	C [auth A], D [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.273 (Depositor)
• R-Value Work:  0.198 (Depositor)
• R-Value Observed: 0.202 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 93.442	α = 90
b = 93.442	β = 90
c = 81.042	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
ADSC	data collection
HKL-2000	data reduction
SCALEPACK	data scaling
SOLVE	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-10-30
Deposition Author(s): Padmanabhan, B., Bessho, Y., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History

• Version 1.0: 2007-10-30
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Derived calculations, Source and taxonomy, Version format compliance
• Version 1.2: 2024-10-09
  Changes: Data collection, Database references, Derived calculations, Structure summary
