2YWX | pdb_00002ywx

Crystal structure of phosphoribosylaminoimidazole carboxylase catalytic subunit from Methanocaldococcus jannaschii

PDB DOI: https://doi.org/10.2210/pdb2YWX/pdb

Classification: LYASE
Organism(s): Methanocaldococcus jannaschii
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2007-04-23 Released: 2007-10-23
Deposition Author(s): Kanagawa, M., Baba, S., Kuramitsu, S., Yokoyama, S., Kawai, G., Sampei, G., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.31 Å
R-Value Free:
0.240 (Depositor), 0.237 (DCC)
R-Value Work:
0.230 (Depositor), 0.229 (DCC)
R-Value Observed:
0.230 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2YWX

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of phosphoribosylaminoimidazole carboxylase catalytic subunit from Methanocaldococcus jannaschii

Kanagawa, M., Baba, S., Kuramitsu, S., Yokoyama, S., Kawai, G., Sampei, G.

To be published.

Macromolecule Content

Total Structure Weight: 16.97 kDa
Atom Count: 1,213
Modeled Residue Count: 157
Deposited Residue Count: 157
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphoribosylaminoimidazole carboxylase catalytic subunit	A	157	Methanocaldococcus jannaschii	Mutation(s): 0 EC: 4.1.1.21 (PDB Primary Data), 5.4.99.18 (UniProt)
UniProt
Find proteins for Q58033 (Methanocaldococcus jannaschii (strain ATCC 43067 / DSM 2661 / JAL-1 / JCM 10045 / NBRC 100440)) Explore Q58033 Go to UniProtKB: Q58033
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q58033
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.31 Å
R-Value Free: 0.240 (Depositor), 0.237 (DCC)
R-Value Work: 0.230 (Depositor), 0.229 (DCC)
R-Value Observed: 0.230 (Depositor)

Space Group: I 4 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 100.887	α = 90
b = 100.887	β = 90
c = 70.912	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
HKL-2000	data collection
HKL-2000	data reduction
HKL-2000	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-10-23

Deposition Author(s):

RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History (Full details and data files)

Version 1.0: 2007-10-23
Type: Initial release
Version 1.1: 2011-07-13
Changes: Derived calculations, Version format compliance
Version 1.2: 2023-10-25
Changes: Data collection, Database references, Refinement description
