2YJZ

Rat STEAP4 oxidoreductase domain complexed with NADP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.203

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

The Crystal Structure of Six-Transmembrane Epithelial Antigen of the Prostate 4 (Steap4), a Ferri/Cuprireductase, Suggests a Novel Interdomain Flavin-Binding Site.

Gauss, G.H.Kleven, M.D.Sendamarai, A.K.Fleming, M.D.Lawrence, C.M.

(2013) J.Biol.Chem. 288: 20668

  • DOI: 10.1074/jbc.M113.479154

  • PubMed Abstract:
  • Steap4 is a cell surface metalloreductase linked to obesity-associated insulin resistance. Initial characterization of its cell surface metalloreductase activity has been reported, but thorough biochemical characterization of this activity is lacking ...

    Steap4 is a cell surface metalloreductase linked to obesity-associated insulin resistance. Initial characterization of its cell surface metalloreductase activity has been reported, but thorough biochemical characterization of this activity is lacking. Here, we report detailed kinetic analysis of the Steap4 cell surface metalloreductase activities. Steap4 shows physiologically relevant Km values for both Fe(3+) and Cu(2+) and retains activity at acidic pH, suggesting it may also function within intracellular organelles to reduce these metals. Flavin-dependent NADPH oxidase activity that was much greater than the equivalent Steap3 construct was observed for the isolated N-terminal oxidoreductase domain. The crystal structure of the Steap4 oxidoreductase domain was determined, providing a structural explanation for these differing activities. Structure-function work also suggested Steap4 utilizes an interdomain flavin-binding site to shuttle electrons between the oxidoreductase and transmembrane domains, and it showed that the disordered N-terminal residues do not contribute to enzymatic activity.


    Organizational Affiliation

    Department of Chemistry and Biochemistry, Montana State University, Bozeman, Montana 59717, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
METALLOREDUCTASE STEAP4
A, B, C, D
201Rattus norvegicusMutation(s): 0
Gene Names: Steap4
EC: 1.16.1.9
Find proteins for Q4V8K1 (Rattus norvegicus)
Go to UniProtKB:  Q4V8K1
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B, C, D
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
NAP
Query on NAP

Download SDF File
Download CCD File
A, B, C, D
NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
2'-MONOPHOSPHOADENOSINE 5'-DIPHOSPHORIBOSE
C21 H28 N7 O17 P3
XJLXINKUBYWONI-NNYOXOHSSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.203
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 69.228α = 90.00
b = 85.111β = 90.00
c = 128.035γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data scaling
MrBUMPphasing
HKL-2000data reduction
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2012-05-30
    Type: Initial release
  • Version 1.1: 2013-07-31
    Type: Database references
