2YCR

Crystal structure of checkpoint kinase 2 in complex with inhibitor PV976


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.200
  • R-Value Observed: 0.202

wwPDB Validation 3D Report Full Report



Literature

Structural Characterization of Inhibitor Complexes with Checkpoint Kinase 2 (Chk2), a Drug Target for Cancer Therapy.

Lountos, G.T.Jobson, A.G.Tropea, J.E.Self, C.R.Zhang, G.Pommier, Y.Shoemaker, R.H.Waugh, D.S.

(2011) J Struct Biol 176: 292

  • DOI: 10.1016/j.jsb.2011.09.008
  • Primary Citation of Related Structures:
    2XK9, 2YCQ, 2YCR, 2YCS, 2YCF

  • PubMed Abstract:
  • Chk2 (checkpoint kinase 2) is a serine/threonine kinase that participates in a series of signaling networks responsible for maintaining genomic integrity and responding to DNA damage. The development of selective Chk2 inhibitors has recently attracte ...

    Chk2 (checkpoint kinase 2) is a serine/threonine kinase that participates in a series of signaling networks responsible for maintaining genomic integrity and responding to DNA damage. The development of selective Chk2 inhibitors has recently attracted much interest as a means of sensitizing cancer cells to current DNA-damaging agents used in the treatment of cancer. Additionally, selective Chk2 inhibitors may reduce p53-mediated apoptosis in normal tissues, thereby helping to mitigate adverse side effects from chemotherapy and radiation. Thus far, relatively few selective inhibitors of Chk2 have been described and none have yet progressed into clinical trials. Here, we report crystal structures of the catalytic domain of Chk2 in complex with a novel series of potent and selective small molecule inhibitors. These compounds exhibit nanomolar potencies and are selective for Chk2 over Chk1. The structures reported here elucidate the binding modes of these inhibitors to Chk2 and provide information that can be exploited for the structure-assisted design of novel chemotherapeutics.


    Organizational Affiliation

    Center for Cancer Research, National Cancer Institute at Frederick, Frederick, MD 21702-1201, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
SERINE/THREONINE-PROTEIN KINASE CHK2A323Homo sapiensMutation(s): 0
Gene Names: CHEK2CDS1CHK2RAD53
EC: 2.7.11.1
Find proteins for O96017 (Homo sapiens)
Explore O96017
Go to UniProtKB:  O96017
NIH Common Fund Data Resources
PHAROS  O96017
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
HCW
Query on HCW

Download CCD File
A
1,3-BIS{4-[(1E)-N-(4,5-DIHYDRO-1H-IMIDAZOL-2-YL)ETHANEHYDRAZONOYL]PHENYL}UREA
C23 H28 N10 O
IGZOGYCMSGAQFP-KUGLDEIXSA-N
 Ligand Interaction
NO3
Query on NO3

Download CCD File
A
NITRATE ION
N O3
NHNBFGGVMKEFGY-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
HCWIC50:  69.5999984741211   nM  Binding MOAD
HCWIC50 :  69.5999984741211   nM  PDBBind
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.200
  • R-Value Observed: 0.202
  • Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 90.801α = 90
b = 90.801β = 90
c = 93.382γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
HKL-3000data reduction
SCALEPACKdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2011-11-16
    Type: Initial release
