2XO2 | pdb_00002xo2

Human Annexin V with incorporated Methionine analogue Azidohomoalanine

• PDB DOI: https://doi.org/10.2210/pdb2XO2/pdb

• Classification: MEMBRANE BINDING PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2010-08-09 Released: 2011-08-03
• Deposition Author(s): Debela, M., Merkel, L., Goettig, P., Budisa, N.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.80 Å
• R-Value Free:
  0.296 (Depositor), 0.300 (DCC)
• R-Value Work:
  0.274 (Depositor), 0.270 (DCC)
• R-Value Observed:
  0.274 (Depositor)

Starting Model: experimental

Literature

Non-Canonical Amino Acids for Click Chemistry Reactions Incorporated in Human Annexin V

Debela, M., Merkel, L., Goettig, P., Budisa, N.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 36.28 kDa
• Atom Count: 2,635
• Modeled Residue Count: 318
• Deposited Residue Count: 320
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ANNEXIN A5	A	320	Homo sapiens	Mutation(s): 8
UniProt & NIH Common Fund Data Resources
Find proteins for P08758 (Homo sapiens) Explore P08758  Go to UniProtKB:  P08758
PHAROS:  P08758 GTEx:  ENSG00000164111

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	E [auth A], F [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
CA	B [auth A], C [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N
CL	G [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA	D [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
AZH	A	L-PEPTIDE LINKING	C4 H9 N4 O2		ALA

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.80 Å
• R-Value Free:  0.296 (Depositor), 0.300 (DCC)
• R-Value Work:  0.274 (Depositor), 0.270 (DCC)
• R-Value Observed: 0.274 (Depositor)

Space Group: H 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 152.708	α = 90
b = 152.708	β = 90
c = 33.603	γ = 120

Software Package:

Software Name	Purpose
CNS	refinement
MOSFLM	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-08-03
Deposition Author(s): Debela, M., Merkel, L., Goettig, P., Budisa, N.

Revision History

• Version 1.0: 2011-08-03
  Type: Initial release

• Version 2.0: 2019-04-24
  Changes: Advisory, Data collection, Derived calculations, Other, Polymer sequence
• Version 2.1: 2023-12-20
  Changes: Advisory, Data collection, Database references, Derived calculations, Other, Refinement description
