2XHN

Rhamnogalacturonan lyase from Aspergillus aculeatus K150A active site mutant


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.52 Å
  • R-Value Free: 0.164
  • R-Value Work: 0.113

wwPDB Validation 3D Report Full Report


This is version 2.0 of the entry. See complete history

Literature

Structural and Biochemical Studies Elucidate the Mechanism of Rhamnogalacturonan Lyase from Aspergillus Aculeatus.

Jensen, M.H.Otten, H.Christensen, U.Borchert, T.V.Christensen, L.L.H.Larsen, S.Leggio, L.L.

(2010) J.Mol.Biol. 404: 100

  • DOI: 10.1016/j.jmb.2010.09.013
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • We present here the first experimental evidence for bound substrate in the active site of a rhamnogalacturonan lyase belonging to family 4 of polysaccharide lyases, Aspergillus aculeatus rhamnogalacturonan lyase (RGL4). RGL4 is involved in the degrad ...

    We present here the first experimental evidence for bound substrate in the active site of a rhamnogalacturonan lyase belonging to family 4 of polysaccharide lyases, Aspergillus aculeatus rhamnogalacturonan lyase (RGL4). RGL4 is involved in the degradation of rhamnogalacturonan-I, an important pectic plant cell wall polysaccharide. Based on the previously determined wild-type structure, enzyme variants RGL4_H210A and RGL4_K150A have been produced and characterized both kinetically and structurally, showing that His210 and Lys150 are key active-site residues. Crystals of the RGL4_K150A variant soaked with a rhamnogalacturonan digest gave a clear picture of substrate bound in the -3/+3 subsites. The crystallographic and kinetic studies on RGL4, and structural and sequence comparison to other enzymes in the same and other PL families, enable us to propose a detailed reaction mechanism for the β-elimination on [-,2)-α-l-rhamno-(1,4)-α-d-galacturonic acid-(1,-]. The mechanism differs significantly from the one established for pectate lyases, in which most often calcium ions are engaged in catalysis.


    Organizational Affiliation

    Biophysical Chemistry Group, Department of Chemistry, University of Copenhagen, 2100 Copenhagen Ø, Denmark.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
RHAMNOGALACTURONASE B
A, B
508Aspergillus aculeatusMutation(s): 1
Gene Names: rglA (RGL4)
EC: 4.2.2.23
Find proteins for Q00019 (Aspergillus aculeatus)
Go to UniProtKB:  Q00019
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
A, B
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
EDO
Query on EDO

Download SDF File
Download CCD File
A
1,2-ETHANEDIOL
ETHYLENE GLYCOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.52 Å
  • R-Value Free: 0.164
  • R-Value Work: 0.113
  • Space Group: C 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 108.934α = 90.00
b = 108.978β = 90.00
c = 170.650γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
PHENIXphasing
DENZOdata reduction
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-09-29
    Type: Initial release
  • Version 1.1: 2011-05-08
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 2.0: 2018-01-17
    Type: Atomic model, Data collection
