2X7R

Crystal structure of a late fusion intermediate of HIV-1 gp41


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.177

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Crystal Structure of HIV-1 Gp41 Including Both Fusion Peptide and Membrane Proximal External Regions.

Buzon, V.Natrajan, G.Schibli, D.Campelo, F.Kozlov, M.M.Weissenhorn, W.

(2010) Plos Pathog. 6: 880

  • DOI: 10.1371/journal.ppat.1000880

  • PubMed Abstract:
  • The HIV-1 envelope glycoprotein (Env) composed of the receptor binding domain gp120 and the fusion protein subunit gp41 catalyzes virus entry and is a major target for therapeutic intervention and for neutralizing antibodies. Env interactions with ce ...

    The HIV-1 envelope glycoprotein (Env) composed of the receptor binding domain gp120 and the fusion protein subunit gp41 catalyzes virus entry and is a major target for therapeutic intervention and for neutralizing antibodies. Env interactions with cellular receptors trigger refolding of gp41, which induces close apposition of viral and cellular membranes leading to membrane fusion. The energy released during refolding is used to overcome the kinetic barrier and drives the fusion reaction. Here, we report the crystal structure at 2 A resolution of the complete extracellular domain of gp41 lacking the fusion peptide and the cystein-linked loop. Both the fusion peptide proximal region (FPPR) and the membrane proximal external region (MPER) form helical extensions from the gp41 six-helical bundle core structure. The lack of regular coiled-coil interactions within FPPR and MPER splay this end of the structure apart while positioning the fusion peptide towards the outside of the six-helical bundle and exposing conserved hydrophobic MPER residues. Unexpectedly, the section of the MPER, which is juxtaposed to the transmembrane region (TMR), bends in a 90 degrees-angle sideward positioning three aromatic side chains per monomer for membrane insertion. We calculate that this structural motif might facilitate the generation of membrane curvature on the viral membrane. The presence of FPPR and MPER increases the melting temperature of gp41 significantly in comparison to the core structure of gp41. Thus, our data indicate that the ordered assembly of FPPR and MPER beyond the core contributes energy to the membrane fusion reaction. Furthermore, we provide the first structural evidence that part of MPER will be membrane inserted within trimeric gp41. We propose that this framework has important implications for membrane bending on the viral membrane, which is required for fusion and could provide a platform for epitope and lipid bilayer recognition for broadly neutralizing gp41 antibodies.


    Organizational Affiliation

    Unit of Virus Host Cell Interactions UMI 3265, Université Joseph Fourier-EMBL-CNRS, Grenoble, France.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
TRANSMEMBRANE PROTEIN GP41
A, D, N
62Human immunodeficiency virus type 1 group M subtype B (isolate LW123)Mutation(s): 0
Gene Names: env
Find proteins for Q70626 (Human immunodeficiency virus type 1 group M subtype B (isolate LW123))
Go to UniProtKB:  Q70626
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
TRANSMEMBRANE PROTEIN GP41
B, C, E
63Human immunodeficiency virus type 1 group M subtype B (isolate LW123)Mutation(s): 0
Gene Names: env
Find proteins for Q70626 (Human immunodeficiency virus type 1 group M subtype B (isolate LW123))
Go to UniProtKB:  Q70626
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download SDF File
Download CCD File
A, B, E
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download SDF File
Download CCD File
E
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.177
  • Space Group: P 63
Unit Cell:
Length (Å)Angle (°)
a = 57.422α = 90.00
b = 57.422β = 90.00
c = 182.768γ = 120.00
Software Package:
Software NamePurpose
PHENIXrefinement
iMOSFLMdata reduction
SCALAdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-05-26
    Type: Initial release
  • Version 1.1: 2011-05-08
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
