2X7L | pdb_00002x7l

Implications of the HIV-1 Rev dimer structure at 3.2A resolution for multimeric binding to the Rev response element


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.17 Å
  • R-Value Free:
    0.250 (Depositor), 0.264 (DCC)
  • R-Value Work:
    0.234 (Depositor), 0.251 (DCC)
  • R-Value Observed:
    0.235 (Depositor)

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2X7L

This is version 1.4 of the entry. See complete history

Literature

Implications of the HIV-1 Rev Dimer Structure at 3. 2 A Resolution for Multimeric Binding to the Rev Response Element.

Dimattia, M.A.Watts, N.R.Stahl, S.J.Rader, C.Wingfield, P.T.Stuart, D.I.Steven, A.C.Grimes, J.M.

(2010) Proc Natl Acad Sci U S A 107: 5810

  • DOI: https://doi.org/10.1073/pnas.0914946107
  • Primary Citation Related Structures:
    2X7L

  • PubMed Abstract:

    HIV-1 Rev is a small regulatory protein that mediates the nuclear export of viral mRNAs, an essential step in the HIV replication cycle. In this process Rev oligomerizes in association with a highly structured RNA motif, the Rev response element. Crystallographic studies of Rev have been hampered by the protein's tendency to aggregate, but Rev has now been found to form a stable soluble equimolar complex with a specifically engineered monoclonal Fab fragment. We have determined the structure of this complex at 3.2 A resolution. It reveals a molecular dimer of Rev, bound on either side by a Fab, where the ordered portion of each Rev monomer (residues 9-65) contains two coplanar alpha-helices arranged in hairpin fashion. Subunits dimerize through overlapping of the hairpin prongs. Mating of hydrophobic patches on the outer surface of the dimer is likely to promote higher order interactions, suggesting a model for Rev oligomerization onto the viral RNA.


  • Organizational Affiliation
    • Division of Structural Biology, Wellcome Trust Centre for Human Genetics, Oxford University, Roosevelt Drive, Oxford OX3 7BN, UK.

Macromolecule Content

  • Total Structure Weight: 365 kDa
  • Atom Count: 22,554
  • Modeled Residue Count: 2,970
  • Deposited Residue Count: 3,378
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
FAB HEAVY CHAIN
A, C, E, G, H
A, C, E, G, H, J
231synthetic constructMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
FAB LIGHT CHAIN
B, D, F, I, K
B, D, F, I, K, L
217synthetic constructMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
PROTEIN REV
M, N, O, P, Q
M, N, O, P, Q, R
115Human immunodeficiency virus type 1 BH10Mutation(s): 0
UniProt
Find proteins for P04616 (Human immunodeficiency virus type 1 group M subtype B (isolate BH10))
Explore P04616
Go to UniProtKB:  P04616
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04616
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.17 Å
  • R-Value Free:  0.250 (Depositor), 0.264 (DCC)
  • R-Value Work:  0.234 (Depositor), 0.251 (DCC)
  • R-Value Observed: 0.235 (Depositor)
Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.678α = 94.86
b = 87.692β = 95.5
c = 176.334γ = 104.6
Software Package:
Software NamePurpose
BUSTERrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-03-23
    Type: Initial release
  • Version 1.1: 2013-09-18
    Changes: Data collection, Database references, Derived calculations, Refinement description, Source and taxonomy, Structure summary, Version format compliance
  • Version 1.2: 2019-02-20
    Changes: Data collection, Other, Source and taxonomy
  • Version 1.3: 2023-12-20
    Changes: Data collection, Database references, Other, Refinement description
  • Version 1.4: 2024-11-13
    Changes: Structure summary
