2X49

Crystal structure of the C-terminal domain of InvA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.192

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Crystal Structure of the C-Terminal Domain of the Salmonella Type III Secretion System Export Apparatus Protein Inva.

Worrall, L.J.Vuckovic, M.Strynadka, N.C.J.

(2010) Protein Sci. 19: 1091

  • DOI: 10.1002/pro.382
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • InvA is a prominent inner-membrane component of the Salmonella type III secretion system (T3SS) apparatus, which is responsible for regulating virulence protein export in pathogenic bacteria. InvA is made up of an N-terminal integral membrane domain ...

    InvA is a prominent inner-membrane component of the Salmonella type III secretion system (T3SS) apparatus, which is responsible for regulating virulence protein export in pathogenic bacteria. InvA is made up of an N-terminal integral membrane domain and a C-terminal cytoplasmic domain that is proposed to form part of a docking platform for the soluble export apparatus proteins notably the T3SS ATPase InvC. Here, we report the novel crystal structure of the C-terminal domain of Salmonella InvA which shows a compact structure composed of four subdomains. The overall structure is unique although the first and second subdomains exhibit structural similarity to the peripheral stalk of the A/V-type ATPase and a ring building motif found in other T3SS proteins respectively.


    Organizational Affiliation

    Centre for Blood Research, Department of Biochemistry and Molecular Biology, University of British Columbia, Life Sciences Centre, British Columbia, Canada V6T 1Z3.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
INVASION PROTEIN INVA
A
333Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720)Mutation(s): 0
Gene Names: invA
Find proteins for P0A1I3 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720))
Go to UniProtKB:  P0A1I3
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA
Query on CA

Download SDF File
Download CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
PEG
Query on PEG

Download SDF File
Download CCD File
A
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
 Ligand Interaction
HG
Query on HG

Download SDF File
Download CCD File
A
MERCURY (II) ION
Hg
BQPIGGFYSBELGY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.192
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 44.991α = 90.00
b = 57.413β = 90.00
c = 113.870γ = 90.00
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling
autoSHARPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-03-31
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Advisory, Version format compliance
