2WVJ | pdb_00002wvj

Mutation of Thr163 to Ser in Human Thymidine Kinase Shifts the Specificity from Thymidine towards the Nucleoside Analogue Azidothymidine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:
    0.221 (Depositor), 0.221 (DCC)
  • R-Value Work:
    0.173 (Depositor), 0.173 (DCC)
  • R-Value Observed:
    0.176 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2WVJ

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Comparative Active-Site Mutation Study of Human and Caenorhabditis Elegans Thymidine Kinase 1.

Skovgaard, T.Uhlin, U.Munch-Petersen, B.

(2012) FEBS J 279: 1777

  • DOI: https://doi.org/10.1111/j.1742-4658.2012.08554.x
  • Primary Citation Related Structures:
    2WVJ

  • PubMed Abstract:

    The first step for the intracellular retention of several anticancer or antiviral nucleoside analogues is the addition of a phosphate group catalysed by a deoxyribonucleoside kinase such as thymidine kinase 1 (TK1). Recently, human TK1 (HuTK1) has been crystallized and characterized using different ligands. To improve our understanding of TK1 substrate specificity, we performed a detailed, mutation-based comparative structure-function study of the active sites of two thymidine kinases: HuTK1 and Caenorhabditis elegans TK1 (CeTK1). Specifically, mutations were introduced into the hydrophobic pocket surrounding the substrate base. In CeTK1, some of these mutations led to increased activity with deoxycytidine and deoxyguanosine, two unusual substrates for TK1-like kinases. In HuTK1, mutation of T163 to S resulted in a kinase with a 140-fold lower K(m) for the antiviral nucleoside analogue 3'-azido-3'-deoxythymidine (AZT) compared with the natural substrate thymidine. The crystal structure of the T163S-mutated HuTK1 reveals a less ordered conformation of the ligand thymidine triphosphate compared with the wild-type structure but the cause of the changed specificity towards AZT is not obvious. Based on its highly increased AZT activity relative to thymidine activity this TK1 mutant could be suitable for suicide gene therapy.


  • Organizational Affiliation
    • Department of Science, Systems and Models, Roskilde University, Denmark. tine.skovgaard@cpr.ku.dk

Macromolecule Content

  • Total Structure Weight: 174.96 kDa
  • Atom Count: 11,307
  • Modeled Residue Count: 1,290
  • Deposited Residue Count: 1,544
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
THYMIDINE KINASE, CYTOSOLIC
A, B, C, D, E
A, B, C, D, E, F, G, H
193Homo sapiensMutation(s): 1
EC: 2.7.1.21
UniProt & NIH Common Fund Data Resources
Find proteins for P04183 (Homo sapiens)
Explore P04183
Go to UniProtKB:  P04183
PHAROS:  P04183
GTEx:  ENSG00000167900
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04183
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TTP

Query on TTP



Download:Ideal Coordinates CCD File
I [auth A]
K [auth B]
M [auth C]
O [auth D]
R [auth E]
I [auth A],
K [auth B],
M [auth C],
O [auth D],
R [auth E],
T [auth F],
V [auth G],
Y [auth H]
THYMIDINE-5'-TRIPHOSPHATE
C10 H17 N2 O14 P3
NHVNXKFIZYSCEB-XLPZGREQSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
AA [auth H]
J [auth A]
L [auth B]
N [auth C]
Q [auth D]
AA [auth H],
J [auth A],
L [auth B],
N [auth C],
Q [auth D],
S [auth E],
U [auth F],
X [auth G]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
P [auth D],
W [auth G],
Z [auth H]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:  0.221 (Depositor), 0.221 (DCC)
  • R-Value Work:  0.173 (Depositor), 0.173 (DCC)
  • R-Value Observed: 0.176 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 156.902α = 90
b = 123.252β = 132.98
c = 121.024γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-10-27
    Type: Initial release
  • Version 1.1: 2012-05-02
    Changes: Database references, Derived calculations, Version format compliance
  • Version 1.2: 2019-05-08
    Changes: Data collection, Experimental preparation, Other
  • Version 1.3: 2023-12-20
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
