2WTH | pdb_00002wth

Low resolution 3D structure of C.elegans globin-like protein (GLB-1): P3121 crystal form


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:
    0.319 (Depositor), 0.348 (DCC)
  • R-Value Work:
    0.269 (Depositor), 0.297 (DCC)
  • R-Value Observed:
    0.271 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2WTH

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Globin-Like Proteins in Caenorhabditis Elegans: In Vivo Localization, Ligand Binding and Structural Properties.

Geuens, E.Hoogewijs, D.Nardini, M.Vinck, E.Pesce, A.Kiger, L.Fago, A.Tilleman, L.De Henau, S.Marden, M.Weber, R.E.Van Doorslaer, S.Vanfleteren, J.Moens, L.Bolognesi, M.Dewilde, S.

(2010) BMC Biochem 11: 17

  • DOI: https://doi.org/10.1186/1471-2091-11-17
  • Primary Citation Related Structures:
    2WTG, 2WTH

  • PubMed Abstract:

    The genome of the nematode Caenorhabditis elegans contains more than 30 putative globin genes that all are transcribed. Although their translated amino acid sequences fit the globin fold, a variety of amino-acid substitutions and extensions generate a wide structural diversity among the putative globins. No information is available on the physicochemical properties and the in vivo expression. We expressed the globins in a bacterial system, characterized the purified proteins by optical and resonance Raman spectroscopy, measured the kinetics and equilibria of O2 binding and determined the crystal structure of GLB-1* (CysGH2 --> Ser mutant). Furthermore, we studied the expression patterns of glb-1 (ZK637.13) and glb-26 (T22C1.2) in the worms using green fluorescent protein technology and measured alterations of their transcript abundances under hypoxic conditions.GLB-1* displays the classical three-over-three alpha-helical sandwich of vertebrate globins, assembled in a homodimer associated through facing E- and F-helices. Within the heme pocket the dioxygen molecule is stabilized by a hydrogen bonded network including TyrB10 and GlnE7.GLB-1 exhibits high ligand affinity, which is, however, lower than in other globins with the same distal TyrB10-GlnE7 amino-acid pair. In the absence of external ligands, the heme ferrous iron of GLB-26 is strongly hexacoordinated with HisE7, which could explain its extremely low affinity for CO. This globin oxidizes instantly to the ferric form in the presence of oxygen and is therefore incapable of reversible oxygen binding. The presented data indicate that GLB-1 and GLB-26 belong to two functionally-different globin classes.


  • Organizational Affiliation
    • Department of Biomedical Sciences, University of Antwerp, Universiteitsplein 1, B-2610 Antwerp, Belgium.

Macromolecule Content

  • Total Structure Weight: 39.16 kDa
  • Atom Count: 2,775
  • Modeled Residue Count: 316
  • Deposited Residue Count: 318
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
GLOBIN-LIKE PROTEIN
A, B
159Caenorhabditis elegansMutation(s): 1
UniProt
Find proteins for P30627 (Caenorhabditis elegans)
Explore P30627
Go to UniProtKB:  P30627
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP30627
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
HEM

Query on HEM



Download:Ideal Coordinates CCD File
C [auth A],
H [auth B]
PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
SO4

Query on SO4



Download:Ideal Coordinates CCD File
E [auth A],
J [auth B],
M [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL

Query on GOL



Download:Ideal Coordinates CCD File
F [auth A]
G [auth A]
K [auth B]
L [auth B]
N [auth B]
F [auth A],
G [auth A],
K [auth B],
L [auth B],
N [auth B],
O [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
OXY

Query on OXY



Download:Ideal Coordinates CCD File
D [auth A],
I [auth B]
OXYGEN MOLECULE
O2
MYMOFIZGZYHOMD-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:  0.319 (Depositor), 0.348 (DCC)
  • R-Value Work:  0.269 (Depositor), 0.297 (DCC)
  • R-Value Observed: 0.271 (Depositor)
Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 77.681α = 90
b = 77.681β = 90
c = 145.64γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2010-04-21
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-12-20
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
