2WGQ

Zinc substituted E Coli Copper Amine Oxidase, a model for the precursor for 2,4,5-trihydroxyphenylalaninequinone formation


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.204

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

The Structure of E Coli Amine Oxidase with the Cataltyic Copper Subsituted for Zinc - a Model Precursor.

Moody, P.C.E.Cooper, R.A.

To be published.

Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
AMINE OXIDASE
A, B
727Escherichia coli (strain K12)Mutation(s): 0
Gene Names: tynA (maoA)
EC: 1.4.3.21
Find proteins for P46883 (Escherichia coli (strain K12))
Go to UniProtKB:  P46883
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A, B
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
A, B
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.204
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 134.680α = 90.00
b = 166.210β = 90.00
c = 79.420γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
REFMACrefinement
DENZOdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2009-06-09
    Type: Initial release
  • Version 1.1: 2011-05-08
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
