crystal structure of linear di-ubiquitin

Experimental Data Snapshot

  • Resolution: 2.25 Å
  • R-Value Free: 0.276
  • R-Value Work: 0.259
  • R-Value Observed: 0.260

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Molecular Discrimination of Structurally Equivalent Lys 63-Linked and Linear Polyubiquitin Chains.

Komander, D.Reyes-Turcu, F.Licchesi, J.D.Odenwaelder, P.Wilkinson, K.D.Barford, D.

(2009) EMBO Rep 10: 466

  • DOI: https://doi.org/10.1038/embor.2009.55
  • Primary Citation of Related Structures:
    2JF5, 2W9N

  • PubMed Abstract:

    At least eight types of ubiquitin chain exist, and individual linkages affect distinct cellular processes. The only distinguishing feature of differently linked ubiquitin chains is their structure, as polymers of the same unit are chemically identical. Here, we have crystallized Lys 63-linked and linear ubiquitin dimers, revealing that both adopt equivalent open conformations, forming no contacts between ubiquitin molecules and thereby differing significantly from Lys 48-linked ubiquitin chains. We also examined the specificity of various deubiquitinases (DUBs) and ubiquitin-binding domains (UBDs). All analysed DUBs, except CYLD, cleave linear chains less efficiently compared with other chain types, or not at all. Likewise, UBDs can show chain specificity, and are able to select distinct linkages from a ubiquitin chain mixture. We found that the UBAN (ubiquitin binding in ABIN and NEMO) motif of NEMO (NF-kappaB essential modifier) binds to linear chains exclusively, whereas the NZF (Npl4 zinc finger) domain of TAB2 (TAK1 binding protein 2) is Lys 63 specific. Our results highlight remarkable specificity determinants within the ubiquitin system.

  • Organizational Affiliation

    Division of Protein and Nucleic Acid Chemistry, Medical Research Council Laboratory of Molecular Biology, Hills Road, Cambridge CB2 0QH, UK. dk@mrc-lmb.cam.ac.uk

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
UBIQUITIN152Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P0CG48 (Homo sapiens)
Explore P0CG48
Go to UniProtKB:  P0CG48
GTEx:  ENSG00000150991
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0CG48
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.25 Å
  • R-Value Free: 0.276
  • R-Value Work: 0.259
  • R-Value Observed: 0.260
  • Space Group: P 43 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 105.572α = 90
b = 105.572β = 90
c = 105.572γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-04-28
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Version format compliance
  • Version 1.2: 2023-12-13
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
