2VON | pdb_00002von

Crystal structure of N-terminal domains of Human La protein complexed with RNA oligomer AUAAUUU


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:
    0.260 (Depositor), 0.301 (DCC)
  • R-Value Work:
    0.230 (Depositor), 0.276 (DCC)
  • R-Value Observed:
    0.230 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2VON

This is version 1.4 of the entry. See complete history

Literature

Structural Analysis Reveals Conformational Plasticity in the Recognition of RNA 3' Ends by the Human La Protein.

Kotik-Kogan, O.Valentine, E.R.Sanfelice, D.Conte, M.R.Curry, S.

(2008) Structure 16: 852

  • DOI: https://doi.org/10.1016/j.str.2008.02.021
  • Primary Citation Related Structures:
    2VOD, 2VON, 2VOO, 2VOP

  • PubMed Abstract:

    The eukaryotic La protein recognizes the 3' poly(U) sequences of nascent RNA polymerase III transcripts to assist folding and maturation. The 3' ends of such RNAs are bound by the N-terminal domain of La (LaNTD). We have solved the crystal structures of four LaNTD:RNA complexes, each containing a different single-stranded RNA oligomer, and compared them to the structure of a previously published LaNTD:RNA complex containing partially duplex RNA. The presence of purely single-stranded RNA in the binding pocket at the interface between the La motif and RRM domains allows significantly closer contact with the 3' end of the RNA. Comparison of the different LaNTD:RNA complexes identifies a conserved set of interactions with the last two nucleotides at the 3' end of the RNA ligand that are key to binding. Strikingly, we also observe two alternative conformations of bound ssRNA, indicative of an unexpected degree of plasticity in the modes of RNA binding.


  • Organizational Affiliation
    • Biophysics Section, Blackett Laboratory, Imperial College, Exhibition Road, London, United Kingdom.

Macromolecule Content

  • Total Structure Weight: 49.39 kDa
  • Atom Count: 3,520
  • Modeled Residue Count: 387
  • Deposited Residue Count: 400
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
LUPUS LA PROTEIN
A, B
193Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P05455 (Homo sapiens)
Explore P05455
Go to UniProtKB:  P05455
PHAROS:  P05455
GTEx:  ENSG00000138385
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP05455
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
5'-R(*AP*UP*AP*AP*UP*UP*UP)-3'
C, D
7Homo sapiens
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:  0.260 (Depositor), 0.301 (DCC)
  • R-Value Work:  0.230 (Depositor), 0.276 (DCC)
  • R-Value Observed: 0.230 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 140.029α = 90
b = 44.471β = 114.35
c = 91.285γ = 90
Software Package:
Software NamePurpose
CNSrefinement
MOSFLMdata reduction
SCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-05-06
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2019-10-09
    Changes: Data collection, Experimental preparation, Other
  • Version 1.4: 2023-12-13
    Changes: Data collection, Database references, Refinement description
