2VIX

Methylated Shigella flexneri MxiC


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.244

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structures of the Shigella Flexneri Type 3 Secretion System Protein Mxic Reveal Conformational Variability Amongst Homologues.

Deane, J.E.Roversi, P.King, C.Johnson, S.Lea, S.M.

(2008) J.Mol.Biol. 377: 985

  • DOI: 10.1016/j.jmb.2008.01.072
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Many Gram-negative pathogenic bacteria use a complex macromolecular machine, known as the type 3 secretion system (T3SS), to transfer virulence proteins into host cells. The T3SS is composed of a cytoplasmic bulb, a basal body spanning the inner and ...

    Many Gram-negative pathogenic bacteria use a complex macromolecular machine, known as the type 3 secretion system (T3SS), to transfer virulence proteins into host cells. The T3SS is composed of a cytoplasmic bulb, a basal body spanning the inner and outer bacterial membranes, and an extracellular needle. Secretion is regulated by both cytoplasmic and inner membrane proteins that must respond to specific signals in order to ensure that virulence proteins are not secreted before contact with a eukaryotic cell. This negative regulation is mediated, in part, by a family of proteins that are thought to physically block the entrance to the secretion apparatus until an appropriate signal is received following host cell contact. Despite weak sequence homology between proteins of this family, the crystal structures of Shigella flexneri MxiC we present here confirm the conservation of domain topology with the homologue from Yersinia sp. Interestingly, comparison of the Shigella and Yersinia structures reveals a significant structural change that results in substantial domain re-arrangement and opening of one face of the molecule. The conservation of a negatively charged patch on this face suggests it may have a role in binding other components of the T3SS.


    Organizational Affiliation

    Sir William Dunn School of Pathology, South Parks Rd, University of Oxford, Oxford OX1 3RE, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
PROTEIN MXIC
A, B, C
294Shigella flexneriMutation(s): 0
Gene Names: mxiC
Find proteins for Q04640 (Shigella flexneri)
Go to UniProtKB:  Q04640
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ACT
Query on ACT

Download SDF File
Download CCD File
A
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
A, B
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MLY
Query on MLY
A, B, C
L-PEPTIDE LINKINGC8 H18 N2 O2LYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.244
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 88.791α = 90.00
b = 102.572β = 90.00
c = 122.638γ = 90.00
Software Package:
Software NamePurpose
PHASERphasing
TNTrefinement
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-03-11
    Type: Initial release
  • Version 1.1: 2011-05-08
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
