2UVE

Structure of Yersinia enterocolitica Family 28 Exopolygalacturonase

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.185
  • R-Value Observed: 0.187

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

The Structural Basis for Exopolygalacturonase Activity in a Family 28 Glycoside Hydrolase.

Abbott, D.W., Boraston, A.B.

(2007) J Mol Biol 368: 1215

  • DOI: https://doi.org/10.1016/j.jmb.2007.02.083
  • Primary Citation of Related Structures:
    2UVE, 2UVF

  • PubMed Abstract:

    • Family 28 glycoside hydrolases (polygalacturonases) are found in organisms across the plant, fungal and bacterial kingdoms, where they are central to diverse biological functions such as fruit ripening, biomass recycling and plant pathogenesis. The structures of several polygalacturonases have been reported; however, all of these enzymes utilize an endo-mode of digestion, which generates a spectrum of oligosaccharide products with varying degrees of polymerization ...

    Family 28 glycoside hydrolases (polygalacturonases) are found in organisms across the plant, fungal and bacterial kingdoms, where they are central to diverse biological functions such as fruit ripening, biomass recycling and plant pathogenesis. The structures of several polygalacturonases have been reported; however, all of these enzymes utilize an endo-mode of digestion, which generates a spectrum of oligosaccharide products with varying degrees of polymerization. The structure of a complementary exo-acting polygalacturonase and an accompanying explanation of the molecular determinants for its specialized activity have been noticeably lacking. We present the structure of an exopolygalacturonase from Yersinia enterocolitica, YeGH28 in a native form (solved to 2.19 A resolution) and a digalacturonic acid product complex (solved to 2.10 A resolution). The activity of YeGH28 is due to inserted stretches of amino acid residues that transform the active site from the open-ended channel observed in the endopolygalacturonases to a closed pocket that restricts the enzyme to the exclusive attack of the non-reducing end of oligogalacturonide substrates. In addition, YeGH28 possesses a fused FN3 domain with unknown function, the first such structure described in pectin active enzymes.

    Organizational Affiliation:

    Biochemistry and Microbiology, University of Victoria, PO Box 3055 STN CSC, Victoria BC, Canada V8W 3P6.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
EXOPOLYGALACTURONASEA, B608Yersinia enterocoliticaMutation(s): 0
UniProt
Find proteins for O68975 (Yersinia enterocolitica)
Explore O68975
Go to UniProtKB:  O68975
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO68975
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4
Download Ideal Coordinates CCD File
AA [auth B],
BA [auth B],
CA [auth B],
DA [auth B],
G [auth A],
AA [auth B],
BA [auth B],
CA [auth B],
DA [auth B],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
W [auth B],
X [auth B],
Y [auth B],
Z [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L		 Ligand Interaction
ACT
Query on ACT
Download Ideal Coordinates CCD File
EA [auth B]ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M		 Ligand Interaction
NI
Query on NI
Download Ideal Coordinates CCD File
C [auth A],
D [auth A],
E [auth A],
F [auth A],
R [auth B],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
R [auth B],
S [auth B],
T [auth B],
U [auth B],
V [auth B]
NICKEL (II) ION
Ni
VEQPNABPJHWNSG-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.185
  • R-Value Observed: 0.187
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 89.952α = 90
b = 78.763β = 103.61
c = 98.192γ = 90
Software Package:
Software NamePurpose
REFMACrefinement

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-05-08
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
