2RKI

Crystal Structure of HIV-1 Reverse Transcriptase (RT) in Complex with a triazole derived NNRTI


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.270
  • R-Value Work: 0.216

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Triazole derivatives as non-nucleoside inhibitors of HIV-1 reverse transcriptase-structure-activity relationships and crystallographic analysis.

Kirschberg, T.A.Balakrishnan, M.Huang, W.Hluhanich, R.Kutty, N.Liclican, A.C.McColl, D.J.Squires, N.H.Lansdon, E.B.

(2008) Bioorg Med Chem Lett 18: 1131-1134

  • DOI: 10.1016/j.bmcl.2007.11.127
  • Primary Citation of Related Structures:
    2RKI

  • PubMed Abstract:
  • A series of 3,4,5-trisubstituted 1,2,4-4H triazole derivatives was synthesized and investigated for HIV-1 reverse transcriptase inhibition. An X-ray structure with HIV-1 RT secured the binding mode and allowed the key interactions with the enzyme to be identified ...

    A series of 3,4,5-trisubstituted 1,2,4-4H triazole derivatives was synthesized and investigated for HIV-1 reverse transcriptase inhibition. An X-ray structure with HIV-1 RT secured the binding mode and allowed the key interactions with the enzyme to be identified.


    Organizational Affiliation

    Gilead Sciences, Department of Medicinal Chemistry, 333 Lakeside Drive, Foster City, CA 94404, USA. tkirschberg@gilead.com



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
HIV-1 reverse transcriptase (RT) p66A560Human immunodeficiency virus 1Mutation(s): 0
Gene Names: gag-pol
EC: 2.7.7.49 (PDB Primary Data), 3.4.23.16 (UniProt), 2.7.7.7 (UniProt), 3.1.26.13 (UniProt), 3.1.13.2 (UniProt), 2.7.7 (UniProt), 3.1 (UniProt)
UniProt
Find proteins for P04585 (Human immunodeficiency virus type 1 group M subtype B (isolate HXB2))
Explore P04585
Go to UniProtKB:  P04585
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04585
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
HIV-1 reverse transcriptase (RT) p51B440Human immunodeficiency virus 1Mutation(s): 0
Gene Names: gag-pol
EC: 2.7.7.49 (PDB Primary Data), 3.4.23.16 (UniProt), 2.7.7.7 (UniProt), 3.1.26.13 (UniProt), 3.1.13.2 (UniProt), 2.7.7 (UniProt), 3.1 (UniProt)
UniProt
Find proteins for P04585 (Human immunodeficiency virus type 1 group M subtype B (isolate HXB2))
Explore P04585
Go to UniProtKB:  P04585
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04585
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
TT1
Query on TT1

Download Ideal Coordinates CCD File
C [auth A]4-benzyl-3-[(2-chlorobenzyl)sulfanyl]-5-thiophen-2-yl-4H-1,2,4-triazole
C20 H16 Cl N3 S2
FMDVHVQWAJPVKM-UHFFFAOYSA-N
 Ligand Interaction
SO4
Query on SO4

Download Ideal Coordinates CCD File
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
GOL
Query on GOL

Download Ideal Coordinates CCD File
D [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download Ideal Coordinates CCD File
J [auth A],
L [auth B],
M [auth B],
N [auth B],
O [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
MG
Query on MG

Download Ideal Coordinates CCD File
K [auth A]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.270
  • R-Value Work: 0.216
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 118.391α = 90
b = 154.167β = 90
c = 154.488γ = 90
Software Package:
Software NamePurpose
CNXrefinement
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling
AMoREphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-04-22
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Non-polymer description, Version format compliance
