2R9L

Polymerase Domain from Mycobacterium tuberculosis Ligase D in complex with DNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.4 Å
  • R-Value Free: 0.272
  • R-Value Work: 0.227

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structure of a NHEJ polymerase-mediated DNA synaptic complex

Brissett, N.C.Pitcher, R.S.Juarez, R.Picher, A.J.Green, A.J.Dafforn, T.R.Fox, G.C.Blanco, L.Doherty, A.J.

(2007) Science 318: 456-459

  • DOI: 10.1126/science.1145112

  • PubMed Abstract:
  • Nonhomologous end joining (NHEJ) is a critical DNA double-strand break (DSB) repair pathway required to maintain genome stability. Many prokaryotes possess a minimalist NHEJ apparatus required to repair DSBs during stationary phase, composed of two c ...

    Nonhomologous end joining (NHEJ) is a critical DNA double-strand break (DSB) repair pathway required to maintain genome stability. Many prokaryotes possess a minimalist NHEJ apparatus required to repair DSBs during stationary phase, composed of two conserved core proteins, Ku and ligase D (LigD). The crystal structure of Mycobacterium tuberculosis polymerase domain of LigD mediating the synapsis of two noncomplementary DNA ends revealed a variety of interactions, including microhomology base pairing, mismatched and flipped-out bases, and 3' termini forming hairpin-like ends. Biochemical and biophysical studies confirmed that polymerase-induced end synapsis also occurs in solution. We propose that this DNA synaptic structure reflects an intermediate bridging stage of the NHEJ process, before end processing and ligation, with both the polymerase and the DNA sequence playing pivotal roles in determining the sequential order of synapsis and remodeling before end joining.


    Organizational Affiliation

    Genome Damage and Stability Centre, University of Sussex, Brighton BN1 9RQ, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
Putative DNA ligase-like protein
A, B
303Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)Mutation(s): 0
Gene Names: ligD
Find proteins for P9WNV3 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Go to UniProtKB:  P9WNV3
Entity ID: 1
MoleculeChainsLengthOrganism
DNA (5'-D(P*DGP*DCP*DGP*DGP*DC)-3')C,E5synthetic construct
Entity ID: 2
MoleculeChainsLengthOrganism
DNA (5'-D(*DGP*DCP*DCP*DGP*DCP*DAP*DAP*DCP*DGP*DCP*DA)-3')D11synthetic construct
Entity ID: 3
MoleculeChainsLengthOrganism
DNA (5'-D(*DGP*DCP*DCP*DGP*DCP*DAP*DAP*DCP*DGP*DCP*DAP*DCP*DG)-3')F13synthetic construct
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
EDO
Query on EDO

Download SDF File
Download CCD File
A, B
1,2-ETHANEDIOL
ETHYLENE GLYCOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
PEG
Query on PEG

Download SDF File
Download CCD File
A
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.4 Å
  • R-Value Free: 0.272
  • R-Value Work: 0.227
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 48.531α = 90.00
b = 111.788β = 90.00
c = 139.542γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
REFMACrefinement
PHASERphasing
PDB_EXTRACTdata extraction
DENZOdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-01-08
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Advisory, Version format compliance
  • Version 1.2: 2017-10-25
    Type: Advisory, Refinement description, Source and taxonomy
