2QZG | pdb_00002qzg

Crystal structure of unknown function protein MMP1188

PDB DOI: https://doi.org/10.2210/pdb2QZG/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Methanococcus maripaludis S2
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2007-08-16 Released: 2007-09-04
Deposition Author(s): Chang, C., Perez, V., Volkart, L., Freeman, L., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.09 Å
R-Value Free:
0.262 (Depositor), 0.266 (DCC)
R-Value Work:
0.208 (Depositor), 0.207 (DCC)
R-Value Observed:
0.211 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2QZG

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of MMP1188, unknown function protein.

Chang, C., Volkart, L., Freeman, L., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 42.63 kDa
Atom Count: 2,885
Modeled Residue Count: 352
Deposited Residue Count: 376
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Conserved uncharacterized archaeal protein	A, B, C, D	94	Methanococcus maripaludis S2	Mutation(s): 0 Gene Names: MMP1188
UniProt
Find proteins for Q6LY05 (Methanococcus maripaludis (strain DSM 14266 / JCM 13030 / NBRC 101832 / S2 / LL)) Explore Q6LY05 Go to UniProtKB: Q6LY05
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q6LY05
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.09 Å
R-Value Free: 0.262 (Depositor), 0.266 (DCC)
R-Value Work: 0.208 (Depositor), 0.207 (DCC)
R-Value Observed: 0.211 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.753	α = 90
b = 83.617	β = 111.48
c = 54.583	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-09-04

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2007-09-04
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2024-11-20
Changes: Data collection, Database references, Derived calculations, Structure summary
