2QSI

Crystal structure of putative hydrogenase expression/formation protein hupG from Rhodopseudomonas palustris CGA009

• PDB DOI: https://doi.org/10.2210/pdb2QSI/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Rhodopseudomonas palustris CGA009
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2007-07-31 Released: 2007-08-14
• Deposition Author(s): Nocek, B., Skarina, T., Kagan, O., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.201
• R-Value Work: 0.152
• R-Value Observed: 0.155

Literature

Structure of putative hydrogenase expression/formation protein hupG from Rhodopseudomonas palustris CGA009.

Nocek, B., Skarina, T., Kagan, O., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 29.33 kDa
• Atom Count: 1,934
• Modelled Residue Count: 224
• Deposited Residue Count: 274
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative hydrogenase expression/formation protein hupG	A, B	137	Rhodopseudomonas palustris CGA009	Mutation(s): 0  Gene Names: hupG, RPA0968
UniProt
Find proteins for Q6NB62 (Rhodopseudomonas palustris (strain ATCC BAA-98 / CGA009)) Explore Q6NB62  Go to UniProtKB:  Q6NB62

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
DTT	C [auth A], E [auth B]	2,3-DIHYDROXY-1,4-DITHIOBUTANE C4 H10 O2 S2 VHJLVAABSRFDPM-IMJSIDKUSA-N
GOL	D [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.201
• R-Value Work: 0.152
• R-Value Observed: 0.155
• Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 31.575	α = 107.72
b = 41.126	β = 99.85
c = 46.85	γ = 101.75

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
MLPHARE	phasing
DM	phasing
SOLVE	phasing
RESOLVE	phasing
ARP/wARP	model building
CCP4	phasing
O	model building
Coot	model building
TLSMD	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-08-14
Deposition Author(s): Nocek, B., Skarina, T., Kagan, O., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2007-08-14
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Source and taxonomy, Version format compliance
