2QRU | pdb_00002qru

Crystal structure of an alpha/beta hydrolase superfamily protein from Enterococcus faecalis

• PDB DOI: https://doi.org/10.2210/pdb2QRU/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Enterococcus faecalis V583
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2007-07-29 Released: 2007-09-11
• Deposition Author(s): Cuff, M.E., Volkart, L., Moy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free:
  0.199 (Depositor), 0.196 (DCC)
• R-Value Work:
  0.167 (Depositor), 0.165 (DCC)
• R-Value Observed:
  0.168 (Depositor)

Literature

Structure of an alpha/beta hydrolase superfamily protein from Enterococcus faecalis.

Cuff, M.E., Volkart, L., Moy, S., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 31.84 kDa
• Atom Count: 2,675
• Modeled Residue Count: 272
• Deposited Residue Count: 274
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A	274	Enterococcus faecalis V583	Mutation(s): 0  Gene Names: EF_0381
UniProt
Find proteins for Q838Q5 (Enterococcus faecalis (strain ATCC 700802 / V583)) Explore Q838Q5  Go to UniProtKB:  Q838Q5

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PO4	B [auth A]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K
EDO	C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free:  0.199 (Depositor), 0.196 (DCC)
• R-Value Work:  0.167 (Depositor), 0.165 (DCC)
• R-Value Observed: 0.168 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 99.352	α = 90
b = 50.413	β = 110.27
c = 64.683	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
MLPHARE	phasing
DM	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
SOLVE	phasing
RESOLVE	phasing
ARP/wARP	model building
CCP4	phasing
O	model building
Coot	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-09-11
Deposition Author(s): Cuff, M.E., Volkart, L., Moy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2007-09-11
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Source and taxonomy, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Refinement description
• Version 1.3: 2024-10-16
  Changes: Data collection, Database references, Derived calculations, Structure summary
