2QHR

Crystal structure of the 13F6-1-2 Fab fragment bound to its Ebola virus glycoprotein peptide epitope.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.203

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Complex of a protective antibody with its Ebola virus GP peptide epitope: unusual features of a V lambda x light chain.

Lee, J.E.Kuehne, A.Abelson, D.M.Fusco, M.L.Hart, M.K.Saphire, E.O.

(2008) J Mol Biol 375: 202-216

  • DOI: https://doi.org/10.1016/j.jmb.2007.10.017
  • Primary Citation of Related Structures:
    2QHR

  • PubMed Abstract:

    13F6-1-2 is a murine monoclonal antibody that recognizes the heavily glycosylated mucin-like domain of the Ebola virus virion-attached glycoprotein (GP) and protects animals against lethal viral challenge. Here we present the crystal structure, at 2.0 A, of 13F6-1-2 in complex with its Ebola virus GP peptide epitope. The GP peptide binds in an extended conformation, anchored primarily by interactions with the heavy chain. Two GP residues, Gln P406 and Arg P409, make extensive side-chain hydrogen bond and electrostatic interactions with the antibody and are likely critical for recognition and affinity. The 13F6-1-2 antibody utilizes a rare V lambda(x) light chain. The three light-chain complementarity-determining regions do not adopt canonical conformations and represent new classes of structures distinct from V kappa and other V lambda light chains. In addition, although V lambda(x) had been thought to confer specificity, all light-chain contacts are mediated through germ-line-encoded residues. This structure of an antibody that protects against the Ebola virus now provides a framework for humanization and development of a postexposure immunotherapeutic.


  • Organizational Affiliation

    Department of Immunology, The Scripps Research Institute, 10550 North Torrey Pines Road, La Jolla, CA 92037, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
13F6-1-2 Fab fragment heavy chainA [auth H]222Mus musculusMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
13F6-1-2 Fab fragment V lambda x light chainB [auth L]218Mus musculusMutation(s): 0
UniProt
Find proteins for P01844 (Mus musculus)
Explore P01844
Go to UniProtKB:  P01844
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01844
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Envelope glycoprotein peptideC [auth P]11N/AMutation(s): 0
UniProt
Find proteins for P87671 (Zaire ebolavirus (strain Eckron-76))
Explore P87671
Go to UniProtKB:  P87671
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP87671
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.203
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 68.24α = 90
b = 70.3β = 90
c = 142.12γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
CNSrefinement
d*TREKdata scaling
PDB_EXTRACTdata extraction
d*TREKdata reduction
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-01-22
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2019-07-24
    Changes: Data collection, Refinement description
  • Version 1.3: 2023-08-30
    Changes: Data collection, Database references, Refinement description
