2QH9 | pdb_00002qh9

The crystal structure of a protein of unknown function from Archaeoglobus fulgidus DSM 4304

PDB DOI: https://doi.org/10.2210/pdb2QH9/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Archaeoglobus fulgidus
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2007-07-01 Released: 2007-09-04
Deposition Author(s): Zhang, R., Zhou, M., Gu, M., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.255 (Depositor), 0.278 (DCC)
R-Value Work:
0.224 (Depositor)
R-Value Observed:
0.225 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2QH9

This is version 1.2 of the entry. See complete history.

Literature

The crystal structure of a protein of unknown function from Archaeoglobus fulgidus DSM 4304.

Zhang, R., Zhou, M., Gu, M., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 42.04 kDa
Atom Count: 2,920
Modeled Residue Count: 351
Deposited Residue Count: 368
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
UPF0215 protein AF_1433	A, B	184	Archaeoglobus fulgidus	Mutation(s): 6 Gene Names: GI:2649134, AF_1433
UniProt
Find proteins for O28839 (Archaeoglobus fulgidus (strain ATCC 49558 / DSM 4304 / JCM 9628 / NBRC 100126 / VC-16)) Explore O28839 Go to UniProtKB: O28839
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O28839
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.255 (Depositor), 0.278 (DCC)
R-Value Work: 0.224 (Depositor)
R-Value Observed: 0.225 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 37.705	α = 90
b = 105.337	β = 102.39
c = 46.707	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-2000	data reduction
HKL-2000	data scaling
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2007-09-04

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2007-09-04
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2024-10-09
Changes: Data collection, Database references, Derived calculations, Structure summary
