2Q79

Crystal Structure of single chain E2C from HPV16 with a 12aa linker for monomerization.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.227

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Increased Stability and DNA Site Discrimination of "Single Chain" Variants of the Dimeric beta-Barrel DNA Binding Domain of the Human Papillomavirus E2 Transcriptional Regulator.

Dellarole, M.Sanchez, I.E.Freire, E.Prat-Gay, G.

(2007) Biochemistry 46: 12441-12450

  • DOI: 10.1021/bi701104q

  • PubMed Abstract:
  • Human papillomavirus infects millions of people worldwide and is a causal agent of cervical cancer in women. The HPV E2 protein controls the expression of all viral genes through binding of its dimeric C-terminal domain (E2C) to its target DNA site. ...

    Human papillomavirus infects millions of people worldwide and is a causal agent of cervical cancer in women. The HPV E2 protein controls the expression of all viral genes through binding of its dimeric C-terminal domain (E2C) to its target DNA site. We engineered monomeric versions of the HPV16 E2C, in order to probe the link of the dimeric beta-barrel fold to stability, dimerization, and DNA binding. Two single-chain variants, with 6 and 12 residue linkers (scE2C-6 and scE2C-12), were purified and characterized. Spectroscopy and crystallography show that the native structure is unperturbed in scE2C-12. The single chain variants are stabilized with respect to E2C, with effective concentrations of 0.6 to 6 mM. The early folding events of the E2C dimer and scE2C-12 are very similar and include formation of a compact species in the submillisecond time scale and a non-native monomeric intermediate with a half-life of 25 ms. However, monomerization changes the unfolding mechanism of the linked species from two-state to three-state, with a high-energy intermediate. Binding to the specific target site is up to 5-fold tighter in the single chain variants. Nonspecific DNA binding is up to 7-fold weaker in the single chain variants, leading to an overall 10-fold increased site discrimination capacity, the largest described so far for linked DNA binding domains. Titration calorimetric binding analysis, however, shows almost identical behavior for dimer and single-chain species, suggesting very subtle changes behind the increased specificity. Global analysis of the mechanisms probed suggests that the dynamics of the E2C domain, rather than the structure, are responsible for the differential properties. Thus, the plastic and dimeric nature of the domain did not evolve for a maximum affinity, specificity, and stability of the quaternary structure, likely because of regulatory reasons and for roles other than DNA binding played by partly folded dimeric or monomeric conformers.


    Organizational Affiliation

    Instituto Leloir and IIBBA-Conicet, Patricias Argentinas 435 (1405), Buenos Aires, Argentina.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Regulatory protein E2
A
93Human papillomavirus type 16Mutation(s): 0
Gene Names: E2
Find proteins for P03120 (Human papillomavirus type 16)
Go to UniProtKB:  P03120
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.227
  • Space Group: P 31 2 1
Unit Cell:
Length (Å)Angle (°)
a = 43.165α = 90.00
b = 43.165β = 90.00
c = 74.918γ = 120.00
Software Package:
Software NamePurpose
MAR345dtbdata collection
MOSFLMdata reduction
AMoREphasing
SCALAdata scaling
CNSrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

  • Deposited Date: 2007-06-06
  • Released Date: 2007-10-16
  • Deposition Author(s): Freire, E.

Revision History

  • Version 1.0: 2007-10-16
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Derived calculations, Version format compliance
