2P97 | pdb_00002p97

CRYSTAL STRUCTURE OF A PUTATIVE METAL-DEPENDENT HYDROLASE (AVA_3068) FROM ANABAENA VARIABILIS ATCC 29413 AT 1.65 A RESOLUTION

• PDB DOI: https://doi.org/10.2210/pdb2P97/pdb

• Classification: METAL BINDING PROTEIN
• Organism(s): Trichormus variabilis ATCC 29413
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2007-03-23 Released: 2007-04-17
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free:
  0.189 (Depositor), 0.200 (DCC)
• R-Value Work:
  0.160 (Depositor), 0.170 (DCC)
• R-Value Observed:
  0.162 (Depositor)

Literature

Crystal structure of hypothetical protein (YP_323572.1) from Anabaena variabilis ATCC 29413 at 1.65 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 8-mer - A8

Biological assembly 2 generated by PISA (software)

Biological Assembly 3

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 3 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 45.18 kDa
• Atom Count: 3,936
• Modeled Residue Count: 402
• Deposited Residue Count: 402
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypothetical protein	A, B	201	Trichormus variabilis ATCC 29413	Mutation(s): 3  Gene Names: YP_323572.1, Ava_3068
UniProt
Find proteins for Q3M8K9 (Trichormus variabilis (strain ATCC 29413 / PCC 7937)) Explore Q3M8K9  Go to UniProtKB:  Q3M8K9

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CL	E [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M
MG	C [auth A], D [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free:  0.189 (Depositor), 0.200 (DCC)
• R-Value Work:  0.160 (Depositor), 0.170 (DCC)
• R-Value Observed: 0.162 (Depositor)

Diffraction Data: https://doi.org/10.18430/M32P97

Space Group: P 4₂ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 103.32	α = 90
b = 103.32	β = 90
c = 96.69	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
SHELX	phasing
REFMAC	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-04-17
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2007-04-17
  Type: Initial release

• Version 1.1: 2008-05-01
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.3: 2017-10-18
  Changes: Refinement description
• Version 1.4: 2023-01-25
  Changes: Database references, Derived calculations
• Version 1.5: 2024-10-30
  Changes: Data collection, Refinement description, Structure summary
