2OYT | pdb_00002oyt

Crystal Structure of UNG2/DNA(TM)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.238 (Depositor), 0.235 (DCC)
  • R-Value Work:
    0.192 (Depositor), 0.192 (DCC)
  • R-Value Observed:
    0.194 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2OYT

This is version 1.4 of the entry. See complete history

Literature

Enzymatic capture of an extrahelical thymine in the search for uracil in DNA.

Parker, J.B.Bianchet, M.A.Krosky, D.J.Friedman, J.I.Amzel, L.M.Stivers, J.T.

(2007) Nature 449: 433-437

  • DOI: https://doi.org/10.1038/nature06131
  • Primary Citation Related Structures:
    2OXM, 2OYT

  • PubMed Abstract:

    The enzyme uracil DNA glycosylase (UNG) excises unwanted uracil bases in the genome using an extrahelical base recognition mechanism. Efficient removal of uracil is essential for prevention of C-to-T transition mutations arising from cytosine deamination, cytotoxic U*A pairs arising from incorporation of dUTP in DNA, and for increasing immunoglobulin gene diversity during the acquired immune response. A central event in all of these UNG-mediated processes is the singling out of rare U*A or U*G base pairs in a background of approximately 10(9) T*A or C*G base pairs in the human genome. Here we establish for the human and Escherichia coli enzymes that discrimination of thymine and uracil is initiated by thermally induced opening of T*A and U*A base pairs and not by active participation of the enzyme. Thus, base-pair dynamics has a critical role in the genome-wide search for uracil, and may be involved in initial damage recognition by other DNA repair glycosylases.


  • Organizational Affiliation
    • Department of Pharmacology and Molecular Sciences, Johns Hopkins Medical School, 725 North Wolfe Street, Baltimore, Maryland 21205, USA.

Macromolecule Content

  • Total Structure Weight: 31.21 kDa
  • Atom Count: 2,582
  • Modeled Residue Count: 242
  • Deposited Residue Count: 242
  • Unique protein chains: 1
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Uracil-DNA glycosylase223Homo sapiensMutation(s): 0
Gene Names: UNGDGUUNG1UNG15
EC: 3.2.2 (PDB Primary Data), 3.2.2.27 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P13051 (Homo sapiens)
Explore P13051
Go to UniProtKB:  P13051
PHAROS:  P13051
GTEx:  ENSG00000076248
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13051
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA strand19N/A
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 3
MoleculeChains LengthOrganismImage
DNA strand210N/A
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.238 (Depositor), 0.235 (DCC)
  • R-Value Work:  0.192 (Depositor), 0.192 (DCC)
  • R-Value Observed: 0.194 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.499α = 90
b = 66.318β = 90
c = 100.316γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data collection
HKL-2000data reduction
SCALEPACKdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-10-30
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2014-07-09
    Changes: Non-polymer description
  • Version 1.3: 2018-01-24
    Changes: Structure summary
  • Version 1.4: 2023-08-30
    Changes: Data collection, Database references, Derived calculations, Refinement description
