2OSH

crystal structure of Natratoxin, a snake sPLA2 that blocks A-type K+ channel


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.190
  • R-Value Observed: 0.192

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Crystal structure of Natratoxin, a novel snake secreted phospholipaseA2 neurotoxin from Naja atra venom inhibiting A-type K+ currents.

Hu, P.Sun, L.Zhu, Z.Q.Hou, X.W.Wang, S.Yu, S.S.Wang, H.L.Zhang, P.Wang, M.Niu, L.W.Teng, M.K.Ruan, D.Y.

(2008) Proteins 72: 673-683

  • DOI: 10.1002/prot.21964
  • Primary Citation of Related Structures:
    2OSH

  • PubMed Abstract:
  • Snake secreted phospholipasesA2 (sPLA2s) are widely used as pharmacological tools to investigate their role in diverse pathophysiological processes. Some members of snake venom sPLA2s have been found to block voltage-activated K(+) channels (K(v) channels) ...

    Snake secreted phospholipasesA2 (sPLA2s) are widely used as pharmacological tools to investigate their role in diverse pathophysiological processes. Some members of snake venom sPLA2s have been found to block voltage-activated K(+) channels (K(v) channels). However, most studies involved in their effects on ion channels were indirectly performed on motor nerve terminals while few studies were directly done on native neurons. Here, a novel snake sPLA2 peptide neurotoxin, Natratoxin, composed of 119 amino acid residues and purified from Naja atra venom was reported. It was characterized using whole-cell patch-clamp in acutely dissociated rat dorsal root ganglion (DRG) neurons. It was found to effectively inhibit A-type K(+) currents and cause alterations of channel gating characters, such as the shifts of steady-state activation and inactivation curves to hyperpolarization direction and changes of V(1/2) and slope factor. Therefore, Natratoxin was suggested to be a gating modifier of K(v) channel. In addition, this inhibitory effect was found to be independent of its enzymatic activity. These results suggested that the toxin enacted its inhibitory effect by binding to K(v) channel. To further elucidate the structural basis for this electrophysiological phenomenon, we determined the crystal structure of Natratoxin at 2.2 A resolution by molecular replacement method and refined to an R-factor of 0.190. The observed overall fold has a different structural organization from other K(+) channel inhibitors in animal toxins. Compared with other K(v) channel inhibitors, a similar putative functional surface in its C-terminal was revealed to contribute to protein-protein interaction in such a blocking effect. Our results demonstrated that the spatial distribution of key amino acid residues matters most in the recognition of this toxin towards its channel target rather than its type of fold.


    Organizational Affiliation

    Department of Neurobiology and Biophysics, School of Life Sciences, University of Science and Technology of China, HeFei, Anhui, 230027, People's Republic of China.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Phospholipase A2 1A119Naja atraMutation(s): 0
EC: 3.1.1.4
UniProt
Find proteins for A4FS04 (Naja atra)
Explore A4FS04
Go to UniProtKB:  A4FS04
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.190
  • R-Value Observed: 0.192
  • Space Group: P 41
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.078α = 90
b = 42.078β = 90
c = 64.117γ = 90
Software Package:
Software NamePurpose
SCALAdata scaling
MOLREPphasing
REFMACrefinement
PDB_EXTRACTdata extraction
MAR345data collection
MOSFLMdata reduction
CCP4data scaling

Structure Validation

View Full Validation Report




Entry History

Deposition Data

  • Deposited Date: 2007-02-06
  • Released Date: 2007-03-03
  • Deposition Author(s): Teng, M.K., Sun, L.

Revision History  (Full details and data files)

  • Version 1.0: 2007-03-03
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-18
    Changes: Refinement description
