2L0S

Solution Structure of Human Plasminogen Kringle 3


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 50
  • Conformers Submitted: 20
  • Selection Criteria: structures with the lowest energy

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Human plasminogen kringle 3: solution structure, functional insights, phylogenetic landscape.

Christen, M.T.Frank, P.Schaller, J.Llinas, M.

(2010) Biochemistry 49: 7131-7150

  • DOI: 10.1021/bi100687f

  • PubMed Abstract:
  • Human plasminogen kringle 3 (hPgn K3) domain contains most elements of the canonical lysine-binding site (LBS) found in other Pgn kringles. However, it does not exhibit affinity for either lysine or structurally related zwitterionic ligands. It has b ...

    Human plasminogen kringle 3 (hPgn K3) domain contains most elements of the canonical lysine-binding site (LBS) found in other Pgn kringles. However, it does not exhibit affinity for either lysine or structurally related zwitterionic ligands. It has been shown that lysine-binding activity can be engineered via a Lys57 --> Asp mutation [Burgin, J., and Schaller, J. (2009) Cell. Mol. Life Sci. 55, 135]. Using a recombinant construct expressed in Escherichia coli, the three-dimensional solution structure of hPgn K3 was determined via NMR spectroscopy [heavy atom averaged rmsd = 0.35 +/- 0.07 A (backbone) and 0.75 +/- 0.12 A (all)]. The (1)H/(15)N heteronuclear single-quantum correlated (HSQC) spectra for both wild-type K3 and mutated [r(K57D)K3] structures are essentially identical, implying that the two structures are effectively isomorphous. The affinity of r(K57D)K3 for the lysine analogue trans-(aminomethyl)cyclohexanecarboxylic acid (AMCHA) was investigated from ligand-induced NMR chemical shift perturbations, which enabled for mapping the binding site on the mutated domain surface. The equilibrium association constant, K(a), was determined to be approximately 5.23 +/- 0.03 mM(-1). Homology modeling combined with in silico docking of lysine-like zwitterionic ligands via AutoDock 4.0 supports functionality of the engineered (K57D)K3 LBS, whose electrostatic focal centers are defined by the Arg36/Arg71 cationic and Asp55/Asp57 anionic pairs. Comparison of K3-type sequences from different vertebrates, including kringles from hedgehog apolipoprotein(a) [Apo(a)] and Apo(a)-related (Arp) sequences, reveals that Lys57 is confined to the hPgn variant. Based on the likely phylogeny and ligand affinities of the homologous domains, it is suggested that the hPgn K3 is unique in that all other K3-type domains, including hedgehog Apo(a) and all Arp domains, except K3(1), are predicted to variously exhibit lysine-binding capability. In Arp K3(1) an Arg residue fills site 72, replacing the key aromatic residue found in other kringles, thus interfering with a requisite kringle-ligand hydrophobic interaction.


    Organizational Affiliation

    Department of Chemistry, Carnegie Mellon University, Pittsburgh, Pennsylvania 15213, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Plasminogen
A
83Homo sapiensMutation(s): 1
Gene Names: PLG
EC: 3.4.21.7
Find proteins for P00747 (Homo sapiens)
Go to Gene View: PLG
Go to UniProtKB:  P00747
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 50
  • Conformers Submitted: 20
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-08-04
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
