2KE8

NMR solution structure of metal-modified DNA


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 200
  • Conformers Submitted: 20
  • Selection Criteria: structures with the lowest energy

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Solution structure of a DNA double helix with consecutive metal-mediated base pairs.

Johannsen, S.Megger, N.Bohme, D.Sigel, R.K.Muller, J.

(2010) Nat.Chem. 2: 229-234

  • DOI: 10.1038/nchem.512

  • PubMed Abstract:
  • Metal-mediated base pairs represent a powerful tool for the site-specific functionalization of nucleic acids with metal ions. The development of applications of the metal-modified nucleic acids will depend on the availability of structural informatio ...

    Metal-mediated base pairs represent a powerful tool for the site-specific functionalization of nucleic acids with metal ions. The development of applications of the metal-modified nucleic acids will depend on the availability of structural information on these double helices. We present here the NMR solution structure of a self-complementary DNA oligonucleotide with three consecutive imidazole nucleotides in its centre. In the absence of transition-metal ions, a hairpin structure is adopted with the artificial nucleotides forming the loop. In the presence of Ag(i) ions, a duplex comprising three imidazole-Ag(+)-imidazole base pairs is formed. Direct proof for the formation of metal-mediated base pairs was obtained from ¹J(¹⁵N,¹⁰⁷/¹⁰⁹Ag) couplings upon incorporation of ¹⁵N-labelled imidazole. The duplex adopts a B-type conformation with only minor deviations in the region of the artificial bases. This work represents the first structural characterization of a metal-modified nucleic acid with a continuous stretch of metal-mediated base pairs.


    Organizational Affiliation

    Institute of Inorganic Chemistry, University of Zürich, Winterthurerstr. 190, 8057 Zürich, Switzerland.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsLengthOrganism
DNA (5'-D(*TP*TP*AP*AP*TP*TP*TP*(D33)P*(D33)P*(D33)P*AP*AP*AP*TP*TP*AP*A)-3')A,B17N/A
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
AG
Query on AG

Download SDF File
Download CCD File
A
SILVER ION
Ag
FOIXSVOLVBLSDH-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
D33
Query on D33
A, B
DNA linkingC8 H13 N2 O6 P

--

Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 200
  • Conformers Submitted: 20
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-02-09
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
