Biological Assembly 1

 3D View: Structure | 1D-3D View | Validation Report

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 5.78 kDa
• Atom Count: 402
• Modelled Residue Count: 51
• Deposited Residue Count: 51
• Unique protein chains: 2

2JUV

AbaA3-DKP-insulin

• PDB DOI: 10.2210/pdb2JUV/pdb
• BMRB: 15455

• Classification: HORMONE
• Mutation(s): Yes


• Deposited: 2007-09-05 Released: 2007-10-16
• Deposition Author(s): Huang, K., Chan, S., Hua, Q., Chu, Y., Wang, R., Klaproth, B., Jia, W., Whittaker, J., De Meyts, P., Nakagawa, S.H., Steiner, D.F., Katsoyannis, P.G., Weiss, M.A.

---

Experimental Data Snapshot

• Method: SOLUTION NMR
• Conformers Calculated: 50
• Conformers Submitted: 15
• Selection Criteria: structures with the lowest energy

Literature

The A-chain of Insulin Contacts the Insert Domain of the Insulin Receptor: PHOTO-CROSS-LINKING AND MUTAGENESIS OF A DIABETES-RELATED CREVICE.

Huang, K., Chan, S.J., Hua, Q.X., Chu, Y.C., Wang, R.Y., Klaproth, B., Jia, W., Whittaker, J., De Meyts, P., Nakagawa, S.H., Steiner, D.F., Katsoyannis, P.G., Weiss, M.A.

(2007) J Biol Chem 282: 35337-35349

• PubMed: 17884811
• DOI: 10.1074/jbc.M705996200
• Primary Citation of Related Structures:
  2JUM, 2JUU, 2JUV


• PubMed Abstract:


The contribution of the insulin A-chain to receptor binding is investigated by photo-cross-linking and nonstandard mutagenesis. Studies focus on the role of Val(A3), which projects within a crevice between the A- and B-chains. Engineered receptor alpha-subunits containing specific protease sites ("midi-receptors") are employed to map the site of photo-cross-linking by an analog containing a photoactivable A3 side chain (para-azido-Phe (Pap)). The probe cross-links to a C-terminal peptide (residues 703-719 of the receptor A isoform, KTFEDYLHNVVFVPRPS) containing side chains critical for hormone binding (underlined); the corresponding segment of the holoreceptor was shown previously to cross-link to a Pap(B25)-insulin analog. Because Pap is larger than Val and so may protrude beyond the A3-associated crevice, we investigated analogs containing A3 substitutions comparable in size to Val as follows: Thr, allo-Thr, and alpha-aminobutyric acid (Aba). Substitutions were introduced within an engineered monomer. Whereas previous studies of smaller substitutions (Gly(A3) and Ser(A3)) encountered nonlocal conformational perturbations, NMR structures of the present analogs are similar to wild-type insulin; the variant side chains are accommodated within a native-like crevice with minimal distortion. Receptor binding activities of Aba(A3) and allo-Thr(A3) analogs are reduced at least 10-fold; the activity of Thr(A3)-DKP-insulin is reduced 5-fold. The hormone-receptor interface is presumably destabilized either by a packing defect (Aba(A3)) or by altered polarity (allo-Thr(A3) and Thr(A3)). Our results provide evidence that Val(A3), a site of mutation causing diabetes mellitus, contacts the insert domain-derived tail of the alpha-subunit in a hormone-receptor complex.

---

Organizational Affiliation:

Department of Biochemistry, Case Western Reserve University, Cleveland, Ohio 44106, USA.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Insulin A chain	A	21	N/A	Mutation(s): 1
UniProt & NIH Common Fund Data Resources
Find proteins for P01308 (Homo sapiens) Explore P01308  Go to UniProtKB:  P01308
PHAROS:  P01308

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Insulin B chain	B	30	N/A	Mutation(s): 3
UniProt & NIH Common Fund Data Resources
Find proteins for P01308 (Homo sapiens) Explore P01308  Go to UniProtKB:  P01308
PHAROS:  P01308

Small Molecules

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
ABA	A	L-PEPTIDE LINKING	C4 H9 N O2		ALA

Experimental Data & Validation

Experimental Data

• Method: SOLUTION NMR
• Conformers Calculated: 50
• Conformers Submitted: 15
• Selection Criteria: structures with the lowest energy
• OLDERADO: 2JUV Olderado

Structure Validation

Entry History

Deposition Data

• Deposited Date: 2007-09-05
• Released Date: 2007-10-16
Deposition Author(s): Huang, K., Chan, S., Hua, Q., Chu, Y., Wang, R., Klaproth, B., Jia, W., Whittaker, J., De Meyts, P., Nakagawa, S.H., Steiner, D.F., Katsoyannis, P.G., Weiss, M.A.

Revision History

• Version 1.0: 2007-10-16
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2021-10-20
  Changes: Database references, Derived calculations
