2JIC

High resolution structure of xylanase-II from one micron beam experiment


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.203
  • R-Value Work: 0.181

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Protein Crystallography with a Micrometre-Sized Synchrotron-Radiation Beam.

Moukhametzianov, R.Burghammer, M.Edwards, P.C.Petitdemange, S.Popov, D.Fransen, M.Mcmullan, G.Schertler, G.F.Riekel, C.

(2008) Acta Crystallogr.,Sect.D 64: 158

  • DOI: 10.1107/S090744490705812X

  • PubMed Abstract:
  • For the first time, protein microcrystallography has been performed with a focused synchrotron-radiation beam of 1 microm using a goniometer with a sub-micrometre sphere of confusion. The crystal structure of xylanase II has been determined with a fl ...

    For the first time, protein microcrystallography has been performed with a focused synchrotron-radiation beam of 1 microm using a goniometer with a sub-micrometre sphere of confusion. The crystal structure of xylanase II has been determined with a flux density of about 3 x 10(10) photons s(-1) microm(-2) at the sample. Two sets of diffraction images collected from different sized crystals were shown to comprise data of good quality, which allowed a 1.5 A resolution xylanase II structure to be obtained. The main conclusion of this experiment is that a high-resolution diffraction pattern can be obtained from 20 microm(3) crystal volume, corresponding to about 2 x 10(8) unit cells. Despite the high irradiation dose in this case, it was possible to obtain an excellent high-resolution map and it could be concluded from the individual atomic B-factor patterns that there was no evidence of significant radiation damage. The photoelectron escape from a narrow diffraction channel is a possible reason for reduced radiation damage as indicated by Monte Carlo simulations. These results open many new opportunities in scanning protein microcrystallography and make random data collection from microcrystals a real possibility, therefore enabling structures to be solved from much smaller crystals than previously anticipated as long as the crystallites are well ordered.


    Organizational Affiliation

    MRC Laboratory of Molecular Biology, Hills Road, Cambridge CB2 0QH, England.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
XYLANASE-II
A
190Trichoderma longibrachiatumMutation(s): 0
EC: 3.2.1.8
Find proteins for F8W669 (Trichoderma longibrachiatum)
Go to UniProtKB:  F8W669
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.203
  • R-Value Work: 0.181
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 40.570α = 90.00
b = 38.830β = 110.61
c = 57.340γ = 90.00
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling
MOLREPphasing
CNSrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-05-13
    Type: Initial release
  • Version 1.1: 2012-06-06
    Type: Database references, Derived calculations, Non-polymer description, Other, Refinement description, Version format compliance
