2I51 | pdb_00002i51

CRYSTAL STRUCTURE OF a pyridoxamine 5'-phosphate oxidase-related, FMN binding protein (NPUN_F5749) FROM NOSTOC PUNCTIFORME PCC 73102 AT 1.40 A RESOLUTION

PDB DOI: https://doi.org/10.2210/pdb2I51/pdb

Classification: FLAVOPROTEIN
Organism(s): Nostoc punctiforme PCC 73102
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2006-08-23 Released: 2006-09-05
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.40 Å
R-Value Free:
0.188 (Depositor), 0.197 (DCC)
R-Value Work:
0.165 (Depositor), 0.174 (DCC)
R-Value Observed:
0.166 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of Uncharacterized conserved protein of COG5135 (ZP_00109616.1) from Nostoc punctiforme PCC 73102 at 1.40 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 47.64 kDa
Atom Count: 3,727
Modeled Residue Count: 385
Deposited Residue Count: 390
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized conserved protein of COG5135	A, B	195	Nostoc punctiforme PCC 73102	Mutation(s): 0 Gene Names: ZP_00109616.1
UniProt
Find proteins for B2J933 (Nostoc punctiforme (strain ATCC 29133 / PCC 73102)) Explore B2J933 Go to UniProtKB: B2J933
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	B2J933
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FMN Query on FMN Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain P [auth B] MOL2 format, chain C [auth A] MOL2 format, chain P [auth B] mmCIF format, chain C [auth A] mmCIF format, chain P [auth B]	C [auth A], P [auth B]	FLAVIN MONONUCLEOTIDE C₁₇ H₂₁ N₄ O₉ P FVTCRASFADXXNN-SCRDCRAPSA-N		Interactions Focus chain C [auth A] Focus chain P [auth B] Interactions & Density Focus chain C [auth A] Focus chain P [auth B]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain Y [auth B] MOL2 format, chain Y [auth B] mmCIF format, chain Y [auth B]	Y [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain Y [auth B] Interactions & Density Focus chain Y [auth B]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain U [auth B] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B] mmCIF format, chain U [auth B] mmCIF format, chain V [auth B] mmCIF format, chain W [auth B] mmCIF format, chain X [auth B]	D [auth A] E [auth A] F [auth A] G [auth A] H [auth A] D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], Q [auth B], R [auth B], S [auth B], T [auth B], U [auth B], V [auth B], W [auth B], X [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.40 Å
R-Value Free: 0.188 (Depositor), 0.197 (DCC)
R-Value Work: 0.165 (Depositor), 0.174 (DCC)
R-Value Observed: 0.166 (Depositor)

Diffraction Data: https://doi.org/10.18430/M32I51

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 65.647	α = 90
b = 65.928	β = 90
c = 112.38	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
SHELX	phasing
REFMAC	refinement
SCALA	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction
CCP4	data scaling
autoSHARP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2006-09-05

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2006-09-05
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.3: 2017-10-18
Changes: Refinement description
Version 1.4: 2017-10-25
Changes: Author supporting evidence
Version 1.5: 2024-10-09
Changes: Data collection, Database references, Derived calculations, Structure summary
