2HRZ | pdb_00002hrz

The crystal structure of the nucleoside-diphosphate-sugar epimerase from Agrobacterium tumefaciens

PDB DOI: https://doi.org/10.2210/pdb2HRZ/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Agrobacterium fabrum str. C58
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2006-07-20 Released: 2006-08-22
Deposition Author(s): Zhang, R., Xu, X., Zheng, H., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free:
0.225 (Depositor), 0.223 (DCC)
R-Value Work:
0.185 (Depositor), 0.183 (DCC)
R-Value Observed:
0.186 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2HRZ

This is version 1.3 of the entry. See complete history.

Literature

The crystal structure of the nucleoside-diphosphate-sugar epimerase from Agrobacterium tumefaciens

Zhang, R., Xu, X., Zheng, H., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 37.56 kDa
Atom Count: 2,937
Modeled Residue Count: 342
Deposited Residue Count: 342
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nucleoside-diphosphate-sugar epimerase	A	342	Agrobacterium fabrum str. C58	Mutation(s): 7 Gene Names: AGR_C_4963, Atu2738
UniProt
Find proteins for A9CHF5 (Agrobacterium fabrum (strain C58 / ATCC 33970)) Explore A9CHF5 Go to UniProtKB: A9CHF5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A9CHF5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.225 (Depositor), 0.223 (DCC)
R-Value Work: 0.185 (Depositor), 0.183 (DCC)
R-Value Observed: 0.186 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 112.893	α = 90
b = 112.893	β = 90
c = 52.765	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
HKL-3000	phasing
SHELXE	model building
SOLVE	phasing
RESOLVE	phasing
ARP/wARP	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2006-08-22

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2006-08-22
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.3: 2024-11-13
Changes: Data collection, Database references, Derived calculations, Structure summary
