2H04

Structural studies of protein tyrosine phosphatase beta catalytic domain in complex with inhibitors


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.169
  • R-Value Observed: 0.170

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Design and synthesis of potent, non-peptidic inhibitors of HPTPbeta.

Amarasinghe, K.K.Evdokimov, A.G.Xu, K.Clark, C.M.Maier, M.B.Srivastava, A.Colson, A.O.Gerwe, G.S.Stake, G.E.Howard, B.W.Pokross, M.E.Gray, J.L.Peters, K.G.

(2006) Bioorg Med Chem Lett 16: 4252-4256

  • DOI: https://doi.org/10.1016/j.bmcl.2006.05.074
  • Primary Citation of Related Structures:
    2H02, 2H03, 2H04

  • PubMed Abstract:

    The sulfamic acid phosphotyrosine mimetic was coupled with a previously known malonate template to obtain highly selective and potent inhibitors of HPTPbeta. Potentially hydrolyzable malonate ester functionalities were replaced with 1,2,4-oxadiazoles without a significant effect on HPTPbeta potency.


  • Organizational Affiliation

    Procter & Gamble Pharmaceuticals, Health Care Research Center, Mason, OH 45040, USA. Amarasinghe.kk@pg.com


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Protein tyrosine phosphatase, receptor type, B,313Homo sapiensMutation(s): 0
Gene Names: PTPRB
EC: 3.1.3.48
UniProt & NIH Common Fund Data Resources
Find proteins for P23467 (Homo sapiens)
Explore P23467
Go to UniProtKB:  P23467
PHAROS:  P23467
GTEx:  ENSG00000127329
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP23467
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
4UN
Query on 4UN

Download Ideal Coordinates CCD File
B [auth A]{4-[2,2-BIS(5-METHYL-1,2,4-OXADIAZOL-3-YL)-3-PHENYLPROPYL]PHENYL}SULFAMIC ACID
C21 H21 N5 O5 S
SXDBFKLPNPUPRI-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.169
  • R-Value Observed: 0.170
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 44.803α = 90
b = 70.12β = 90
c = 90.722γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
MAR345data collection
HKL-2000data scaling
AMoREphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-06-13
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-18
    Changes: Refinement description
  • Version 1.4: 2023-08-30
    Changes: Data collection, Database references, Derived calculations, Refinement description
