2GMR | pdb_00002gmr

Photosynthetic reaction center mutant from Rhodobacter sphaeroides with Asp L210 replaced with Asn


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:
    0.250 (Depositor), 0.240 (DCC)
  • R-Value Work:
    0.215 (Depositor), 0.203 (DCC)
  • R-Value Observed:
    0.215 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2GMR

Ligand Structure Quality Assessment


This is version 1.5 of the entry. See complete history

Literature

Proton uptake in the reaction center mutant L210DN from Rhodobacter sphaeroides via protonated water molecules.

Hermes, S.Stachnik, J.M.Onidas, D.Remy, A.Hofmann, E.Gerwert, K.

(2006) Biochemistry 45: 13741-13749

  • DOI: https://doi.org/10.1021/bi060742q
  • Primary Citation Related Structures:
    2GMR

  • PubMed Abstract:

    The reaction center (RC) of Rhodobacter sphaeroides uses light energy to reduce and protonate a quinone molecule, QB (the secondary quinone electron acceptor), to form quinol, QBH2. Asp210 in the L-subunit has been shown to be a catalytic residue in this process. Mutation of Asp210 to Asn leads to a deceleration of reoxidation of QA- in the QA-QB --> QAQB- transition. Here we determined the structure of the Asp210 to Asn mutant to 2.5 A and show that there are no major structural differences as compared to the wild-type protein. We found QB in the distal position and a chain of water molecules between Asn210 and QB. Using time-resolved Fourier transform infrared (trFTIR) spectroscopy, we characterized the molecular reaction mechanism of this mutant. We found that QB- formation precedes QA- oxidation even more pronounced than in the wild-type reaction center. Continuum absorbance changes indicate deprotonation of a protonated water cluster, most likely of the water chain between Asn210 and QB. A detailed analysis of wild-type structures revealed a highly conserved water chain between Asp210 or Glu210 and QB in Rb. sphaeroides and Rhodopseudomonas viridis, respectively.


  • Organizational Affiliation
    • Lehrstuhl für Biophysik, ND 04/596, Ruhr-Universität Bochum, D-44801 Bochum, Germany.

Macromolecule Content

  • Total Structure Weight: 102.53 kDa
  • Atom Count: 7,286
  • Modeled Residue Count: 825
  • Deposited Residue Count: 848
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Photosynthetic Reaction center protein L chainA [auth L]281Cereibacter sphaeroidesMutation(s): 1
Gene Names: pufL
Membrane Entity: Yes
UniProt
Find proteins for P0C0Y8 (Cereibacter sphaeroides)
Explore P0C0Y8
Go to UniProtKB:  P0C0Y8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C0Y8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Photosynthetic Reaction center protein M chainB [auth M]307Cereibacter sphaeroidesMutation(s): 0
Gene Names: pufM
Membrane Entity: Yes
UniProt
Find proteins for P0C0Y9 (Cereibacter sphaeroides)
Explore P0C0Y9
Go to UniProtKB:  P0C0Y9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C0Y9
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Photosynthetic reaction center protein H chainC [auth H]260Cereibacter sphaeroidesMutation(s): 0
Gene Names: puhA
Membrane Entity: Yes
UniProt
Find proteins for P0C0Y7 (Cereibacter sphaeroides)
Explore P0C0Y7
Go to UniProtKB:  P0C0Y7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C0Y7
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
BCL

Query on BCL



Download:Ideal Coordinates CCD File
D [auth L],
E [auth L],
F [auth L],
K [auth M]
BACTERIOCHLOROPHYLL A
C55 H74 Mg N4 O6
DSJXIQQMORJERS-AGGZHOMASA-M
BPH

Query on BPH



Download:Ideal Coordinates CCD File
G [auth L],
L [auth M]
BACTERIOPHEOPHYTIN A
C55 H76 N4 O6
KWOZSBGNAHVCKG-SZQBJALDSA-N
U10

Query on U10



Download:Ideal Coordinates CCD File
H [auth L],
M
UBIQUINONE-10
C59 H90 O4
ACTIUHUUMQJHFO-UPTCCGCDSA-N
SPN

Query on SPN



Download:Ideal Coordinates CCD File
N [auth M]SPEROIDENONE
C41 H70 O2
GWQAMGYOEYXWJF-YCDPMLDASA-N
LDA

Query on LDA



Download:Ideal Coordinates CCD File
I [auth L],
O [auth M],
P [auth M],
Q [auth H]
LAURYL DIMETHYLAMINE-N-OXIDE
C14 H31 N O
SYELZBGXAIXKHU-UHFFFAOYSA-N
FE2

Query on FE2



Download:Ideal Coordinates CCD File
J [auth M]FE (II) ION
Fe
CWYNVVGOOAEACU-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:  0.250 (Depositor), 0.240 (DCC)
  • R-Value Work:  0.215 (Depositor), 0.203 (DCC)
  • R-Value Observed: 0.215 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 76.85α = 90
b = 134.72β = 90
c = 141.64γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
MOLREPphasing
CNSrefinement
PDB_EXTRACTdata extraction
XDSdata reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-11-21
    Type: Initial release
  • Version 1.1: 2007-10-16
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.3: 2018-01-24
    Changes: Advisory, Structure summary
  • Version 1.4: 2021-10-20
    Changes: Advisory, Database references, Derived calculations
  • Version 1.5: 2023-08-30
    Changes: Data collection, Refinement description
